Specifications
1)Perfect working performance
2)Large capacity
3)Long service life
4)BV/CE
China First Manufacturer Honeycomb Briquette Machine/Honeycomb Coal Making Machine/Coal Briquette Production Line
Production description of honeycomb coal briquette machine
This machine is mainly used to make the coal briquettes in honeycomb shapes. This kind of honeycomb briquette has been used in China for almost 80 years. But why ? It just because it has the advantages of full burned due to the holes on the briquettes. Normal cases is a briquette exste burnning 1 hour . Less coal resources left after bruned , just because of the special design of the briquette
honeycomb coal briquette machine Working principle
Loading prepared material into the hopper, distributor will feed material into the molds under the hopper, then the pressure device will press the powder, under the stronger press, powder will be formed to a certain shape. Next, the briquette will be pressed out off the mold by auxiliary punch, and fall on the belt conveyor. With the rotating of dieplate, this process will be continuous.
Characteristics of honeycomb coal briquette machine:
(1) Smokless, smelless, clean and have a long burning time.
(2) High density, high hardness, not easy to broken.
(3) Stable shape and good performance.
(4) Convenient to store and transport.
honeycomb coal briquette machine parameters:
Model | MA140 | MA160 | MA180 | MA220 | MA260 |
Capacity(Punching times per Minute) | 45-50 | 45-50 | 45-50 | 20-24 | 20-24 |
Power(kw) | 7.5 kw; 4pole | 7.5 kw; 4pole | 11 kw; 4pole | 15 kw; 4pole | 15 kw; 4pole |
Presssure(tons) | 20-30 tons | 20-35 tons | 25-35 tons | 30-40 tons | 35-45 tons |
Mode of Operation | Punching press | Punching press | Punching press | Punching press | Punching press |
Diameter Of Mould(mm) | 140 mm | 160 mm | 180 mm | 220 mm | 260 mm |
Diameter of Final Products(mm) | Round:below140mm Square:100*100mm | Round:below160mm Square:120*120mm | Round:below180mm Square:150*150mm | Round:below220mm Square:200*200mm | Round:below260mm Square:220*220mm |
Height of Final Products(mm) | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted |
Shape of final briquettes | Round/square/hexagon/other shape with holes or without holes by customizing the related molds. | ||||
Materials Conditions | Size: Less Than 5 MM ; Moisture: less Than 10% | ||||
Pre-sale service,Installation and After sales service
The Pre-sale service is free, begins with analyzing and planning of your particular needs. Whether you need a single machine, a multi-stage process? Or a production line of complete plant. Henan Machine Co.,Ltd.can advise you on the right solution for the most cost-efficient briquetting.
We can guide you to install the products or directly send our engineer in your country for the installation.
In the after sales service, Henan Machine Co.,Ltd. has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts. Spare and wear parts are always close to you.
Payment,Packing and Delivery
Payment :30% TT in advance, 70%6TT balance pay off before delivery.
Packing: The machine and wear parts will protected by plywooden box or as customers’ will.
Delivery time: For one set, the delivery time is 7-10 days, for 1-5 sets 20-25 days, above 5 sets usually negotiate.
Shipping company: MSK/MSC/APL/EMC/WANHAL/KLINE and We will remind you before boat arrive and offer you all the customs clearance documents on time.
Our factory can according to your requirements for you to customize your required products, customer demand as the first element, ensure the quality at the same time also provide good shopping service for you.Make you buy what you want products.
