Low Price durable honeycomb machine / beehive coal briquette making machine / honeycomb press machine
- 100 Set / Sets per Month
- Qingdao Shanghai Tianjin Lianyungang
- T/T D/P D/A Credit Card PayPal
- Charcoal Briquette Machine with Low Price(0086-15978436639)
- Charcoal Briquetting Process Machine(86-15978436639)
- Briquetting Plant Machine(0086-15978436639)
- Charcoal Briquette Machine China Trade(86-15978436639)
- Charcoal Briquette Machine for Family Use(86-15978436639)
- Granules Charcoal Briquette Machine(0086-15978436639)
Product Details
Production Capacity: | 1-30t/h | Motor Type: | AC Motor | ||
Power(W): | 7.5-22KW, 7.5KW-22KW | Place of Origin: | Henan, China | Brand Name: | Hennan Meshen |
Model Number: | MA140/MA160/MA180/MA220/MA260, MA140/MA160/MA180/MA220/MA260 | Dimension(L*W*H): | According to different types, According to different types | Certification: | CE and ISO approval, CE ISO |
Warranty: | 1 year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Low Price durable honeycomb machine / beehive coal briquette making machine / honeycomb press machine
Charcoal honeycomb briquette making machine take raw coal, charcoal, carbon, carbon black, agricultural waste etc as the raw material, take electricity as the main power. Honeycomb coal briquetting machine can make the raw material into round and square shapes at different specification. We can also produce moulds according to your requirements.
Loading prepared material into the hopper, distributor will feed material into the molds under the hopper, then the pressure device will press the powder, under the stronger press, powder will be formed to a certain shape. Next, the briquette will be pressed out off the mold by auxiliary punch, and fall on the belt conveyor. With the rotating of dieplate, this process will be continuous.
Model | MA140 | MA160 | MA180 | MA220 | MA260 |
Capacity(Punching times per Minute) | 45-50 | 45-50 | 45-50 | 20-24 | 20-24 |
Power(kw) | 7.5 kw; 4pole | 7.5 kw; 4pole | 11 kw; 4pole | 15 kw; 4pole | 15 kw; 4pole |
Presssure(tons) | 20-30 tons | 20-35 tons | 25-35 tons | 30-40 tons | 35-45 tons |
Mode of Operation | Punching press | Punching press | Punching press | Punching press | Punching press |
Diameter Of Mould(mm) | 140 mm | 160 mm | 180 mm | 220 mm | 260 mm |
Diameter of Final Products(mm) | Round:below140mm Square:100*100mm | Round:below160mm Square:120*120mm | Round:below180mm Square:150*150mm | Round:below220mm Square:200*200mm | Round:below260mm Square:220*220mm |
Height of Final Products(mm) | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted |
Shape of final briquettes | Round/square/hexagon/other shape with holes or without holes by customizing the related molds. | ||||
Materials Conditions | Size: Less Than 5 MM ; Moisture: less Than 10% |
Model | MA220 | MA260 | MA2012 |
Capacity(kg/h) | 1000-1500kg/h | 1500-2000kg/h | 2000-3000kg/h |
Power(kw) | 15 kw; 4pole | 15 kw; 4pole | 22kw; 4pole |
Presssure(tons) | 30-40 tons | 35-45 tons | 60-80tons |
Mode of Operation | Punching press | Punching press | Punching press |
Weight(kg) | 4000kg | 5500kg | 8500kg |
Diameter of Final Products(mm) | Round:below220mm Square:200*200mm | Round:below260mm Square:220*220mm | Round:below260mm Square:220*220mm |
Height of Final Products(mm) | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted | 30-90 MM; Can be adjusted |
Shape of final briquettes | Round/square/hexagon/other shape with holes or without holes by customizing the related molds. | ||
Materials Conditions | Size: Less Than 5 MM ; Moisture: less Than 10% |
The Pre-sale service is free, begins with analyzing and planning of your particular needs. Whether you need a single machine, a multi-stage process? Or a production line of complete plant. Henan Machine Co.,Ltd.can advise you on the right solution for the most cost-efficient briquetting.
We can guide you to install the products or directly send our engineer in your country for the installation.
In the after sales service, Henan Machine Co.,Ltd. has a team of briquetting professionals ready to help you. We provide one year warranty for all of our products and six month for the wear parts. Spare and wear parts are always close to you.
1. Payment :30% TT in advance, 70%TT balance pay off before delivery.
2. Packing: The machine and wear parts will protected by plywooden box or as customers’ will
3. Delivery time: For one set, the delivery time is 7-10 days, for 1-5 sets 20-25 days, above 5 sets usually negotiate.
Our factory can according to your requirements for you to customize your required products, customer demand as the first element, ensure the quality at the same time also provide good shopping service for you.Make you buy what you want products.
