screw type sawdust charcoal briquetting machine
1 General Description of screw type sawdust charcoal briquetting machine
Our coal briquettes extruder use the application of the principle of the spiral extrusion , which make it become a certain intensity round or hexagon, triangle, ect charcoal/coal rods by working for the powered coal/charcoal mixed with binder.It is widely used in chemical industry ,metallurgy and ceramic industry , which is the ideal equipments of enterprise specialized in efficient production and reducing consumption.
2 Working principle of screw type sawdust charcoal briquetting machine
3 Outstanding Features of screw type sawdust charcoal briquetting machine
1.big incoming lathe screw constant and faster material processing rate and energy saving !
2.Rigid connection is used between the shaft block and cylinder. The machine Φhave a stable working performance better than ever.
3.Hydraulic coupler drive is used . So the machine is smooth in operation and have small noise, Also have the function of overload protection.
4.Custom-made services are provided.
5 Detailed parameters of screw type sawdust charcoal briquetting machine
Model |
MBJ140 |
MBJ180 |
MBJ300 |
MBJ400 |
Capacity |
1-2T/H for coal; 0.5-1T/H for charcoal |
2-3T/H for coal; 1-1.5T/H for charcoal |
3-5T/H for coal; 1.5-2.5T/H for charcoal |
6-10T/H for coal; 3.0-5.0T/H for charcoal |
|
Diameter of mould |
20-40mm |
20-60mm |
20-80mm |
20-80mm |
Main shaft speed |
46-60r/min |
39-60r/min |
35-60r/min |
35-60r/min |
|
Number of Spiral Blades
|
4 |
4 |
4 |
4 |
Motor |
Y160m-4 11KW Y160L-4 15KW |
Y180m-4 18.5KW Y180L-4 22KW |
Y225s-4 37KW Y225m-4 45KW |
Y315m-4 160KW |
Reducer |
ZQ350 |
ZQ400 |
ZQ650-750 |
ZQ850 |
Bearing |
7511,211,210,1305 |
7614,314,313,1206 |
32320,320,319,1207 |
32322,322,321 |
Note |
Spindle speed is the lowest speed, according to the current size and load weight, increase the level of appropriate yield
|
|||
6 Payment,Packing and Delivery
l Payment :30% TT in advance, 70%6TT balance pay off before delivery.
l Packing: The machine and wear parts will protected by plywooden box or as customers’ will.
l Delivery time: For one set, the delivery time is 7-10 days, for 1-5 sets 20-25 days, above 5 sets usually negotiate.
