Home > Industrial Equipment & Components > Filtration Equipment & Parts > Machine Oil Purifier > DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS,

DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS,

DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, thumbnail-1
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, thumbnail-2
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, thumbnail-3
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, thumbnail-4
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, thumbnail-5
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, photo-1
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, photo-2
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, photo-3
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, photo-4
DAYI 10 MT Capacity More Than 95% Oil Yield Used Engine Oil Recycling Equipment With ISO,CE,SGS, photo-5
US$ 36,000 - 66,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Flow:
80%
Working Pressure:
Normal Pressure
Contact Supplier Request Quote Chat Now
Shangqiu Dayi Electromechanincal Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
LIAN YUNGANG&Qingdao port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Flow 80%
Working Pressure Normal Pressure
Place of Origin Henan, China
Brand Name DYJD
Model Number DYJD -10
Usage Other, distill the engine oil into diesel
Voltage 380V
Power(W) 16KW
Dimension(L*W*H) 5000*1900*1900mm
Weight 37TON
Certification ISO,CE,SGS ,BV
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1,Continuous and negative pressure
2,90%-95% output diesel&gasoline
3,Vaccum system
4,Save energy&time
5,Safety





  10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,



Product Description









Distillation Machine In 3D

DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,Process flow chart




1. Distillation machine list





1)degumming tank



2)flash tank



3)Reboiler



4)Residue oil tank



5)sarkozy dragon buffer tank



6)Resid Temporary storage tank



7)heat exchanger



8)Re-cooler



9)catalyst tower



10)Vacuum buffer tank



11)Vacuum pump



12)strong spray tower



13)liquidometer of flash tank



14)draft fan



15)cooling pool



16)vacuum pool



17)vacuum pressure pump



18)cool water recycling pipe



19)hot water recycling pipe



20)glass sight



21)Air Emission device



22)raw oil transfer pump



23)raw oil recycle pump



24)pressure gauge



25)pressure sensor



26)temperature gauge



27)temperature sensor



28)security valve



29)control panel



30)Negative pressure injector

DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,

2. Raw material:



fuel oil, waste engine oil, tyre oil, waste plastic oil, waste rubber oil,black oil,oil residue,oil sand, oil sludge





3.High configuration



Base of reactor :Stainless steel



Strong spray tower  stainless steel



Activated carbon adsorption tower stainless steel



Draft fan stainless steel





4.End product percentage:



Disel base oil,engine base oil,Diesel,gasoline





5.Working pressure



Completely negative pressure



6.The parameter of waste oil after Distillation





Project

Diesel

Standard

Oxidation Stability

2.2

≤2.5mg/100ml

Sulfur Content (%)

0.03

M/m≤0.2

10% Steamed Residual Carbon Residue (%)

0.33

M/m≤0.3

Ash Content (%)

0.016

%m/m≤.0.01

Density

0.85

0.83-0.87

Solidifying Point/°C

-10

0

Flash Point (closed)/°C

45

55

Movement Viscosity

3.5

(20°C)mm2/s3.0-8.0

Combustion Value

9500

8500

Colority

1.2

≤3.5

Cetane Number

40

45



 Complete Distillation Plant DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,







Packaging & Shipping

 DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,

Our Services



7. After-sale service



1.Quality warranty period: One year warranty for the chamber of the distillation machines,and lifetime maintenance for complete set of machines. pay the double air tickets, accommodation and food.



2.According to the requirement of the buyer, our company sends engineers for installation and commissioning in buyer's site including the training of skills of buyer's workers on operation, maintenance, etc.



3. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the buyer.



8. Advantages





We belong to the environmentally friendly equipment, without produce any pollution to the environment, the exhaust gas can reach international standard.





a.We adopt forced circulation heating, it can reduce the boiling point of product, about half an hour will produce the oil.



b.We take the negative pressure filtration system, no pollution emissions of gases reached national environmental standards.



c.We use the flash, short time-consuming, low energy consumption; at the same time can improve the yield efficiency and product quality.



d.No pollution. National patent of enviroment-friendly plant ,the whole set include smoke and dust seperation system and waste gas recovery system.





e.High output .We can guarantee 85%-95% oil  output rate ,much higher than any other distillation machines.





f.Safety.The whole set of plant are equipped with pressure gage ,thermomter,and vacuum pump.





Customers







DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,



 DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,





Company Information

 DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,





Certificate





DAYI 10 MT capacity more than 95% oil yield used engine oil recycling equipment With ISO,CE,SGS,
