Help CenterDAYI Continous Feeding System.85%-95% Oil Yield Used Waste Engine Oil/pyrolysis Oil Recycle Plant for Sale With CE
Related Products
-
DAYI Waste Tires to Crude Oil Equipment Used Tire Pyrolysis Plant for Sale Waste Tire Pyrolysis Recycling Machine With CEUS$ 36,000 - 70,000MOQ: 1 Set -
DAYI Full Automatic High Quality Waste Tire Recycling to Diesel Machine With Certification of CE,ISO,TUVUS$ 35,000 - 55,000MOQ: 1 Set
-
DAYI 2015 Newest Waste Tyre Pyrolysis Oil Purification Plant/Tire Recycling to Diesel Oil Machine/SystemUS$ 35,000 - 55,000MOQ: 1 Set
-
DAYI CE /SGS/BV/ISO, Profitable Programs Shangqiu DAYI Brand Q345R 16mm Waste Tire Recycling to Diesel/tire Recycling PlantUS$ 35,000 - 55,000MOQ: 1 Set
-
DAYI Used Rubber Tires Recycling Machines /used Tyres Rubber Oil Plant With New Pyrolysis TechnologyUS$ 28,800 - 98,880MOQ: 1 Set
Specification:
1:85%-95% output oil yield
2,continous feeding
3,304S stainless reactor
4,base oil refining
5,CE&ISO9001 ;4001
6.nagative pressure
Continous feeding system.85%-95% oil yield Used waste engine oil/pyrolysis oil recycle plant for sale with CE
| 1.SAFETY |
We have many safety devices like safety valves, alarming ring,automatic decreasing pressure device, oil-water separator, anti-back fire device, negative pressure device.these devices can guarantee the oil gas can not be back to the reactor and the distillation machine is working under the normal pressure.
| 2.ENERGY SAVING |
1)Flame path is designed as spiral so that quantity of heat can be fully used.
2)Tail gas recycle use by the reactor
3)catalyst helps to improve the oil quality
| 3.OUR ADVANTAGES |
a. we use the underground dedusting system , the main part of the dedusting system is called strong spray tower which is made from stainless steel .
b. the security system is composed of two water seals, pressure sensors, temperature sensors and safety valves
c. we use 2 condensers and one set of calandria cooling system to make the cooling line longer and cooling surface wider to get more oil. d. the bottom of the main reactor is also made from stainless steel
e. the filter system can help to get good quality of oil
| 3.SPECIFICATIONS | |
| Items | Contents |
| Raw materials | Heavy oil,fuel oil, furnace oil, pyrolysis oil,crude oil ,used engine oil |
| Average oil yield | 85%~90% |
| Material of Reactor | Q345R boiler steel plate |
| Thickness of Reactor | 16mm |
| Mode of cooling | Water Cooling |
| Power Consumption | 15KW |
| Heating materials | Coal, firewood,oil,natural gas |
| Model | D1500mm*L3000mm (3ton) |
| D2000mm*L5000mm (5ton) | |
| D2800mm*L6000mm (10ton) | |
| Rotate speed | 0.4 |
| Operating pressure | Normal |
4.3. End product percentage:Diesel base oil,engine base oil
4.4. feeding:continuous feeding
4.5.Working pressure:positive and negative pressure
4.6. Cover land:around 200Square meters
4.7. Delivery time:20-25days after we receive deposit.
| 4.8 Capacity and container |
Model | Reactor material | Capacity | Container |
DYZL-05 | 316L stainless steel | 3-5tons | 2*40HQ |
DYZL-10 | 316L stainless steel | 6-10tons | 2*40HQ |
| DYZL-15 | 316L stainless steel | 10-15tons | 2*40HQ |
DYZL-20 | 316L stainless steel | 15-20tons | 3*40HQ |
| DYZL-25 | 316L stainless steel | 20-25tons | 3*40HQ |
DYZL-30 | 316L stainless steel | 25-30tons | 4*40HQ |
1.guarantee of 2 years for he whole machine,except wear piece
2.Based on our customers’ site and budget, our experts will design efficient, reliable installation drawings
4.One a month calling visit, to make sure there is no problems of the equipment
5. 24 hour technical support by e-mail
6.. Professional quotation detail vedio /CD
7.. dispatch engineer within 10 days
