Twist Off Cap Making Line

Jiujiang Yongxin Can Equipment Co., Ltd.

US$ 2,000 - 12,500 MOQ: 1 Set

Key Specifications

Condition:

New

Application:

Beverage, Food

Packaging Type:

Case

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Application Beverage, Food

Packaging Type Case

Packaging Material Wood

Automatic Grade Automatic

Driven Type Electric

Voltage 380V

Power 85KW

Place of Origin Jiangxi, China

Brand Name YX

Model Number Twist off

Weight 2700kg(oven), 2700kg(oven)

Dimension(L*W*H) 6300X1440X2200 mm(oven)

Certification CE

After-sales Service Provided Engineers available to service machinery overseas

Specification&Features

Automatic Twist Off Cap Making Line
	Production capacity	120pcs/min
	Diameter range	30-82mm

GT2TA10 Automatic sheets feeding system with 25 ton press machine
	25T press machine	120 punch/min with single manipulator
	Max tinplate size	1050*1050mm
	Max weight of tinplate	2.5 ton
	With hydraulic lifter for sheets
	With automatic oiling rolling feeding system
	With double sheets checking sensor
	With panasonic CNC 3 AXIS servomotors system
	With panosonic control system
	With electrical system of Schneider

Lining and mouding machine
	Actual capacity	200 pcs/min
	Power consumption	25kw
	Air supplier	About 5.5 bar
	Running mode	multi-station continuously
	Ling model	Lining model
	Weight	2500kg
	Dimension	15009502500mm
	With PLC control, speed of 180-200 caps per min.
	With panasonic frequency invert. Working automatically.
	SMC pneumatic components. With automatic clamp detecting, caps detecting, caps out detecting and doube cap detecting.
GT-2P15 twist off cap ling and moulding forming machine is used for precurling, curling, lug forming and lining the cap. With four function into one machines. After that, the cap goes to drying machine for drying.

Can lid drying machine
	Capacity	200 pcs/min
	Speed adjustment	Line speed 0.9-1.6m/min. Or frequency 10-60 Hz
	Max height	963mm
	Max motor power	58.2KW, 50Hz/380V
	Motor power	5 KW,50Hz/380V
	Dimension	630014402200mm
	Weight	2700kg
This machine is used for drying the compound of the cap which came out from the lining and moulding forming machine.

Counting machine
	Cap diameter	30-150 mm
	Speed	25m/min
	Width of conveyor	300mm
	Height of working table	800mm
	Speed	max 700pcs per min
	Motor power	0.25 KW, 1390/145rpm, 50Hz/380V
	Air compressor	1.6Mpa
	Weight	80kg
	Dimension	17505001120mm
This machine is mainly used for counting the caps after came out from drying machine.
