Aerosol Can Lid Punching Machine

Aerosol Can Lid Punching Machine thumbnail-1
Aerosol Can Lid Punching Machine photo-1
US$ 5,800 - 10,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangxi, China
Brand Name:
Yongxin
Condition:
New
Contact Supplier Request Quote Chat Now
Jiujiang Yongxin Can Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai/jiujiang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangxi, China
Brand Name Yongxin
Condition New
After-sales Service Provided Engineers available to service machinery overseas

Aerosol can Lid Punching Machine

Aerosol can Lid Punching Machine









Specification

1.Horizonal crankshaft

2.Rigid rotated key dutch

3.Manual die height adjustment with scale display.

Nominal force400KN
Nominal stroke6mm
Slide stroke120mm
SPM55/min
Max die height220mm
Die height adjustment80mm
Between slide center and frame260mm
Bolster size480*710mm
Bolster openingΦ220*25* Φ 180mm
Bolster thickness80mm
Bed openingΦ200*150*300mm
Slide area270*320mm
Shank holeΦ50*70mm
Max.inclined angle25°
Between colums300mm
Main motor power4KW
Outline dimension1600*1180*2310mm
Net weight3180kg











































Usage

1.Apply to the welding of vairous can food cans,increased material cans,aerosol cans, chemical tanks

2.Can body internal and extemal prepainting machine and can body drier are optional tobe added in production line



Features



1. PLC(Programmable Logic Controller) is purchased from Japanese MITSUBISHI.

2. Low voltage apparatus are produced by SCHNEIDER.

3. IGBT(Insulated Gate Bipolar Transistor) is bought from Japanese FUJI.

4. OMRON is our sensor supplier.

5. HMI(Human Machine Interface) is purchased from WEINTEC Labs.,Inc in Taiwan.



Can making technology  process

Cutting-----rounding-----welding-----coating-----drying-----necking,flanging,top seaming,bottom seaming-----leaking testing



Applicable types of cans

aerosol can ,food cans ,increased material cans, chemical tanks.



Sample can

Aerosol can Lid Punching Machine





 Aerosol can Lid Punching Machine



Aerosol can Lid Punching Machine

Aerosol can Lid Punching Machine

Aerosol can Lid Punching Machine
