KD Hot Plate For Laboratory
Main function
Liquid or liquid-solid suspended heating and mixing.
Feature
1.30°Working plate suits your seat and perspective)
2.No polar adjust speed digital display rotary speed and control line makes the rotary speed steady or big torque
3. Set in Constant temp line ,temp control accuracy, easy to operate.
4.Inside, outside probe can measure the temp of electric heater and the liquid temp in it.
5.The instrument itself can be Self-protection(over-heating over temp over-limitation).
Technical data
Model |
ZNCL-BS |
|||
Heating plate size (mm) |
140*140 |
180*180 |
230*230 |
280*280 |
Power supply |
220v/50hz |
|||
Speed range(rpm) |
0~2500. Digital speed, stepless speed regulation |
|||
Motor power (W) |
40W, DC14-24V |
|||
Temperature accuracy |
±1℃, Intelligent digital display, internal and external with sensor, SCR control |
|||
Heating temperature |
highest surface temperature is 380 ℃ |
|||
Overtemperature protection |
390 ℃ automatic protection |
|||
Heating power (W) |
350 |
500 |
800 |
1200 |
Face plate material |
Special coating vacuum coating (high temperature resistance, corrosion resistance, resistance to strong acid and alkali, smooth and easy to clean) |
|||
Heating, stirring capacity (mm) |
50-500 beaker |
50-2000 beaker |
50-3000 beaker |
50-5000 beaker |
Overall dimensions |
325*215*120 |
430*270*150 |
500*330*150 |
|
Packing size |
315*205*170 |
375*265*170 |
480*320*200 |
550*380*200 |
Weight (g) |
3200±200 |
4500±200 |
6000±200 |
7500±200 |
Working time |
Continuous |
|||
Other models for your reference
Model |
TWCL-B |
HWCL-B |
ZNCL-B |
ZNCL-BS |
Power supply(V) |
~220V/50HZ |
|||
Temp control range(°C) |
RT-300°C |
|||
Heating Plate Area(W) |
140x140 180x180 230x230 280x280mm Four Kinds |
|||
Heating Power (W) |
200-800W according to model |
|||
Temp control |
Adjust voltage |
Automatic |
Intelligence control inside, outside probe
|
|
Temp control accuracy(°C) |
±5 |
±2 |
±1 |
±1 |
Speed Adjust range(°C) |
0-2000r/min No polar adjust |
Digital display No polar adjust |
||
Motor Power(w) |
8-40 |
|||
