Intelligent Temp Control Heating Magnetic Stirrer
Detail Description
1, Intelligent temperature control
2, flat panel heating
3, magnetic stirring
4, aluminum upper surface
Technical Data
| Model | Accuracy of temp control | Range of temp control | Stir capacity | Temp control mode |
| ZNCL | ±1°c | RT-300°c | 50-20000ml | Intelligent |
Model | ZNCL-BS | |||
Heating plate size (mm) | 140*140 | 180*180 | 230*230 | 280*280 |
Power supply | 220v/50hz | |||
Speed range(rpm) | 0~2500. Digital speed, stepless speed regulation | |||
Motor power (W) | 40W, DC14-24V | |||
Temperature accuracy | ±1℃,Intelligent digital display, internal and external with sensor, SCR control | |||
Heating temperature | highest surface temperature is 380 ℃ | |||
Overtemperature protection | 390 ℃ automatic protection | |||
Heating power (W) | 350 | 500 | 800 | 1200 |
Face plate material | Special coating vacuum coating (high temperature resistance, corrosion resistance, resistance to strong acid and alkali, smooth and easy to clean) | |||
Heating, stirring capacity (mm) | 50-500 beaker | 50-2000 beaker | 50-3000 beaker | 50-5000 beaker |
Overall dimensions | 325*215*120 | 430*270*150 | 500*330*150 | |
Packing size | 315*205*170 | 375*265*170 | 480*320*200 | 550*380*200 |
Weight (g) | 3200±200 | 4500±200 | 6000±200 | 7500±200 |
Working time | Continuous | |||
ZNCL-BS
SZCL-2 1
85-1
The working theory of this product is using micro electrical machinery to drive the heatproof magnet to spin, thus creating a magnetic field. This magnetic field will drive the stir bar to spin in the container and later it will cause spin of the solvent. Meanwhile, it can heat the solvent so that it can be fully mixed at set temperature. This product has been widely applied in biology, medicine, chemistry, chemical engineering and other related fields.
Packaging:
Export standard woden case or as your requirement
Shipping:
Usually we ship the goods by one of three methods as below.You can chose the most appropriate one according to your timeline and budget.Shipping by your own shipping agent is acceptable.
1.Product quality guarentee is for one year,after our Products the date sold.
2.Products in the quality guarantee period, the company responsible for free maintenance and replacement parts.
CE Certification:
Zhengzhou Keda Machinery and Instrument Equipment Co.,Ltd. is specialized in R&D, production, selling, teaching, chemical and biological pharmaceutical equipment integrated company, especially Intelligent PID Temperature Controller, Glass Single Layer Chemical Reactor, and rotatary evaporatator. Company Tanet: Keeping reputation, Valuing contracts, using lower price and better quality instrument equipment to serve the cause of Chinese scientific research.
Factory Size: 1,000-3,000 square meters
Year Established: 2009
Total Revenue : US$1 Million - US$2.5 Million
Registration No.: 410105000067362
Main Markets: Central America,Mid East,Oceania,Africa,South America
1. What's the minimum order quantity?
One set at present.
2. What kind of payment term do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal.
3. How will you delivery these goods?
It will be decided according to your quantity. Normally we will choose International Express, Air and sea.
4. How will package glass equipment?
We package these glass equipment in good and Non fumigation standard plywood.
5. Can you accept OEM terms?
Sure.
If you have any needs please contact me.
We are specialized in R&D, production, selling, teaching, chemical and biological pharmaceutical equipment integrated company.
