KD Hydrothermal Synthesis Reactor Teflon Lined Butterfly Valve
- shanghai dalian qingdao tianjin
- T/T L/C D/P D/A Credit Card PayPal
You May Like
-
KD Hydrothermal Synthesis Reactor With Teflon Pads
-
KD Synthesis Reactor Teflon Pipe Made in China
-
KD 200ml Teflon Lined Piping Reactor Made in China
-
(KD)Advanced Technology Hydrothermal Synthesis Reactor for Chemical Lab Use
-
(KD)New Lab Use Teflon Lined Hydrothermal Synthesis Reactor Made in China
-
KD 50ml Teflon Reaction Vessel
Product Details
| Condition | New | Automatic Grade | Semi-Automatic | |
| Type | Reaction Kettle | Place of Origin | Henan, China | |
| Brand Name | ZZKD | Model Number | KH-50ml | |
| Voltage | . | Power(W) | . | |
| Dimension(L*W*H) | . | Weight | ., 4.2KG | |
| Certification | . | Warranty | one year | |
| After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
KD Hydrothermal Synthesis Reactor Teflon Lined Butterfly Valve
Brief introduction
Hydrothermal synthesis reactor is also called high pressure digestion tank, pressure dissolved shells which is finished by high quality stainless steel and PTFE. It with simple appearance, reasonable structure, while acid, alkali and corrosion are all resistance. Hydrothermal synthesis reactor is achieve the goal of rapid digestion of insoluble material by strong acid or alkali and high temperature and high pressure sealed environment in the tank. It is the right hand in sample digestion when it determined the trace elements and trace elements.
Technical data
Hydrothermal Synthesis Reactor | Model | Capacity(ml) | Material | Remarks |
KH-15 | 15 | Kettle body is stainless steel and the liner is PTFE | Max. Pressure is 3 Mpa | |
KH-25 | 25 | |||
KH-50 | 50 | |||
KH-100 | 100 | |||
KH-150 | 150 | |||
KH-200 | 200 | |||
KH-250 | 250 | |||
KH-300 | 300 | |||
KH-400 | 400 | |||
KH-500 | 500 | |||
KH-1000 | 1000 |
Liner temperaure
Liner temperature | ||
Lining color | Safe temperature (℃) | Max.temperature (℃) |
White | 220 | 240 |
gray | 260 | 280 |
Black | 280 | 300 |
Use and precautions
1. The heating should not exceed 200 ℃, heating rate ≤ 55 ℃ min, PID temperature control system can be used to control the temperature, cooling rate ≤ 5 ℃ min, safety pressure is 3 Mpa.
2. When you completed the reaction, please open the kettle cover until the kettle natural cooling to the room temperature.
3. The degree of filling in kettle should no more than 80%.
Notes: When heated to 100 degrees, please keep for 1 hour and then heated to the desired temperature, to ensure the longevity and safety of the equipment.
Product details
1. What’s the material of the shell?
Usually 304 stainless steel
316 stainless steel is available.
2. What’s the delivery time?
In stock for normal models.
3. How many kinds of your reactor?
Max 240 degree C liner and Max 280 degree C liner.
4. Note:
When heated to 100 degrees, hold for 1 hour and then heated to the required temperature to make sure the long life and safe use.
