KD Jacket Reactor Still for Laboratory
Function introduction
Single layer glass reactor is an equipment which is a collaboration of vacuum state,distillation, reflux, stirring, oil/water heating, heating mantle. It can do all kinds of biochemical reactions and synthesis reactions at a constant temperature condition. It is also a closed system on the whole.Circulating water vacuum pump can pump into the reactor sorts of liquids and gases. The reflux or distillation is possible under different temperature state.The single layer glass reactor has water/oil heating bath or heating mantle itself. Water/oil bath temperature is digital display, which can meet constant temperature state,fast temp. rising, accurate controllers.1-50l is circular and more than 50L is cylinder. After heating we can add the cooling coil in the tank to cool the material in short time.
Features
1.GG17 high-borosilicate glass with nice physical-chemical properties; experiment temperature -100 to 400 degree C; Resistant to strong acidic properties of materials; only touching with glass parts & PTFE, no cross-contamination.
2.Precision Mechanical seal stirring to keep high vacuum degree.
3.Glass(PTFE)discharge valve, no-dead angle mixing, fast no residue discharge.
4. Frequency control speed gear motor, smooth running,high torque, automatic booster, no spark, noise free, long life.
5. SUS frame and cast aluminum material kettle body support, simple as well as strong; stable structure
6.Circulating water/oil bath, heating mantle can supply the heating origin; Cooling mode machine:cool chiller, convenient and practical
Technical Parameter
Model |
F-1L |
F-2L |
F-3L |
F-5L |
F-10L |
F-20L |
F-30L |
F-50L |
F-100L |
Voltage(V/Hz) |
220 50/60 |
380 50/60 |
|||||||
Stirring Power(W) |
60 |
120 |
180 |
||||||
Stirring Speed(rmp) |
0-1000 |
60~600 |
|||||||
Capacity(L) |
1 |
2 |
3 |
5 |
10 |
20 |
30 |
50 |
100 |
Heating Power(kW) |
0.5 |
0.8 |
1.2 |
1.5 |
3 |
4.5 |
6 |
9 |
|
Heating Mantle Power (kw) |
0.53 |
0.65 |
0.73 |
1.1 |
2.1 |
3 |
3.8 |
5 |
...... |
Temperature Using Range(℃) |
RT-250 | RT-350 |
||||||||
Motor Torque(g/cm) |
2000 |
2400 |
4800 |
1000 |
1200 |
1500 |
3000 |
||
The jacket reactor still will be packed in wooden cases or as your request.
Sipment:by sea, air or as your desire!
Products quality guarantee is for one year,after the product was sold.
In the warranty period, the users operate according to instruction and meet problems, and our company maintains free of charge.
Beyond the warranty period, products problems can also be solved by my company maintenance,but charge wiring components fees properly.
Zhengzhou Keda Machinery and Instrument Equipment Co., Ltd.
Our company always adheres to the "quality casting brand, professional achieves service"
business philosophy, and the main product is rotary evaporator, short path distillation, jacketed glass reactor, single layer glass reactor, circulating water vacuum pump, low temperature reaction bath (slot), cooling chiller, vacuum drying oven, blast drying oven, high-pressure reaction kettle, microwave chemical reactor, freeze dryer, water/oil bath, magnetic heating stirrer, hydrothermal synthesis reactor, heating mantle, lift jack, etc.
1,What's the max temperature?
Usually the high borosilicate glass can withstand over 300 degree centigrade and the PTFE stirring bar can withstand about 200 degree centigrade
2,What's the size do you have?
We can offer you 1L,2L,5L, 10L, 20L, 30L, 50L, 100L,150L.
3,How many kinds of your glass reactor?
Two types: jacketed glass reactor and single layer glass reactor.
Explosion proof is available
4,What’s the heating mode of single layer glass reactor?
Oil/water bath heating, and heating mantle
5,Can you offer the supporting facilities?
Yes, we can offer you the vacuum, heating and cooling system as you demand.,
6,What's the minimum order quantity?
One set at present
7,What kind of payment term do you accept?
Normally we accept TT, Paypal, Western Union, Alibaba Escrow, and L/C. The exactly term with be discussed during the deal.
