Help Center600*900mm Microcomputer Flat Bed Screen Printing Press Machine
Related Products
-
Semi Automatic Nonwoven Bag Flat Screen Printing MachineNegotiableMOQ: 1 Set -
800*1200mm High Precision Microcomputer Flat Screen PrinterNegotiableMOQ: 1 Set
-
400*600mm Microcomputer Economic Flat Bed Screen Printing MachineNegotiableMOQ: 1 Set
-
Precision Flatbed Textile Silk Screen Press MachineryNegotiableMOQ: 1 Set
-
High Precision Flatbed PCB Screen PrinterNegotiableMOQ: 1 Set
Characteristics
1.The printing effect is very excellent by using four air cylinders.
2.The height of screen-release device can be quickly adjusted,ensure printing precision and quality.
3.The tension pressure for printing blade,ink-return blade is adjusted separately at infinite speed,which increases the service lift and printing quality of half tone.
4.Printing stroke and half tone fixed system can be quickly adjusted to meet different printing area.
Main Technical Parameters
Model | TH-6090G |
Max.printing acreage | 600*900mm |
Max.Dimension of the frame | 950*1100mm |
Dimensions of the workbench | 800*1000mm |
Printing speed | 1200pcs/h |
Printing to thickness | ~40mm |
Height of instrant off-network | 0-15mm |
Weight(about) | 600kg |
Overall dimensions | 1600*1200*1300mm |
| 3P 380V 50HZ |
Printing motor | 0.75KW |
Printing shaft | 0.75KW |
Wind machine | 1.1KW |
Power | 2.6KW |
