Brief Introduction
The machine is suitable for the packing of global general official A4 ant-static duplicating papers, Instead of manual packaging, labor intensity is reduced, 1 pack / 500sheets After packaging, products are of beautiful appearance, working efficiency is increased. This machine can pack China A4 copy sheets (210×297mm).
Working principle: each bars,horizontally and other sections are driven to run by a series of cams inside the machine. such as automatic feeding paper, falling paper, gluing, wrapping and so on during the process packaging.
Features
1.Multi-functional digital-indication frequency converter, stepless variable speed regulation,PLC control systems are adopted.
2.Touch screen is equipped, so man-machine interface is achieved.
3.With the function of outer packing paper automatically cut and fed.
4. Common or higher-class color printing paper,glazing paper, film laminated paper,film shower paper can be used for outer packing paper.
5.The most advanced automatic glue spraying system is equipped.
6.Packaging costs can be greatly reduced, packaging exactness, effect, sealing capacity are increased.
7.The packing effect can be fully up to the international level
Main Technical Data
Model | FRP-A4 |
Productive capacity | 16-20packs/min
|
Function of whereby roll overwrap paper can be automatically cross cut and fed | 16-20sheet/min |
Specification of packed copy paper | A4:210×297mm |
Power supply | 380v/3phase/4line |
Motor power | 5.1kw |
Gluing power | 2.2kw |
Compressed air | 0.6mpa |
Paper size(length and width) | 550-560mm×386mm |
Overall dimension | 4800×3050×1450mm |
Weight | 1.5t |
Suitable range | Package material for gluing paper of color printing or hexahedral wrapping |
