TianGang Refiner JM-120 Colloid Mill Refiner Soybean Grinder

TianGang Refiner JM-120 Colloid Mill Refiner Soybean Grinder photo-1
US$ 683 - 713 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
Tian Gang
Model Number:
JM-60
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shanghai, China
Brand Name Tian Gang
Model Number JM-60
Type Other, Colloid mill

Voltage:220V/380/50Hz

Power:1500W

Thin degree:2~50μm

Out put:0.05-0.5t/h (Varies According to Materials pepper)

Speed:2880r/min

Size:300*300*650mm

Weight:45kg

  TianGang Refiner JM-120 Colloid mill Refiner soybean grinder

Working principle:
The working principle of the colloidal mill is that: Under the effect of centrifugal force and being run by relatively high speed between the rotating gear and the fixed gear, the liquid and the semi-liquid materials is efficiently emulsified, homogenized, dispersed and mixed during the course of being cut, milled and shocked with high frequency. After that you can get the satisfied and processed material.
Application Scope:
The colloidal mill is widely applied in sorts of products of many fields by its advantage such as foodstuffs industry, medicine industry, chemical industry and everyday chemical industry etc.; the products including soybean milk, fruit jam, peanut butter, artificial corn milk, cream, perfumery compound, pigment, greasing oil, dyestuff, pant, fish live oil, pollen, honey, tooth-paste and so on.



Technical Data

Voltage

Motor Power

Input (According to Materials)

Thin degree

Weight

Size

JM-60

220V 50Hz

1.5KW

0.05-0.5T/Hr

Conical stainless steel

Finess of processed material(2~50μm)

Cooling water tie-in

45Kg

300*300*650mm

JM-80

380V 50Hz

4KW

0.2-1.5T/Hr

95Kg

450*450*800mm

JM-120

380V 50Hz

7.5KW

0.5-2T/Hr

150Kg

550*550*1300mm

JMS-80

380V 50Hz

4KW

0.2-1.5T/Hr

200Kg

450*450*800mm

JMS-120

380V 50Hz

7.5KW

0.5-2T/Hr

250Kg

550*550*1300mm

JMS-130

380V 50Hz

11KW

0.5-2T/Hr

350Kg

550*550*1300mm
