Help CenterStailess Steel Vertical Colloid Mill JM-80 Food Grinding Machine
Related Products
-
FP-05 Shanghai Commercial Red Chili Pepper Making MachineUS$ 570 - 650MOQ: 1 Piece -
FP-05 Shanghai Commercial Chilli Pepper Making MachineUS$ 545 - 570MOQ: 1 Set
-
FP-05 Shanghai Chili Pepper Grinding Machine Chili Paste Making MachineUS$ 550 - 550MOQ: 1 Set
-
FE-05 Shanghai High Speed Food Grinding Machine Rice Soybean Milk Making MachineUS$ 345 - 345MOQ: 1 Set
-
JM-80 Shanghai Full Stainless Still Colloid Mill Almond Butter Paste Making Machine Peanut Butter MachineUS$ 1,300 - 1,400MOQ: 1 Set
Specifications:
JM-80 Colloid mill Grains grinding machine factory direct sales
| Model Number | JM-80 |
| Power | 4KW |
| Voltage | 380/50Hz |
| Speedr | 2880r/min |
| Weight | 95kg |
| Size | 450*450*800mm |
| Thin degree | 2~50μm |
| Out put | 0.2-1.5t/h (Varies According to Materials pioperteies) |
Applications and other futures:
1,Applications: factories which make bean curd, spiced & dried bean curd, soybean milk, etc.
2,Bean grinding, with thickly flavored bean paste emerging all at once, Okara removal accomplished in a single operation, and flaky Okara discharged at the same time.
3,Employing stainless steel and aluminum alloy, beautiful and endurable, no rust build-up, compact size, space saving and facilitates fast cleaning.
4,Special waterproof of motor and the international standard of CE, UL, CSA, ISO9002.
5,Applications wide and extensive including rice milling ,fine grinding of beans, and the soft-soaking of other items.
Almond, sesame, peanut, nuts, rice, beans, fruits, all kinds of grains are both able to process .
The machine details, spares:
The similar products--Other colloid mill:
| Techinical date | Voltage | Motor Power | Input Capacity(According to the materials) | Minimum Degree | Weight | Size |
| JM-60 | 220V50Hz | 1.5Kw | 50-500kg/h | 2-50um | 45kg | 30*30*65cm |
| JM-80 | 380V50Hz | 4Kw | 200-1500kg/h | 2-50um | 95kg | 45*45*80cm |
| JM-120 | 380V50Hz | 7.5Kw | 500-2000kg/h | 2-50um | 150kg | 55*55*130cm |
| JMS-80 | 380V50Hz | 4Kw | 200-1500kg/h | 2-50um | 200kg | 45*45*80cm |
| JMS-120 | 380V50Hz | 7.5Kw | 500-2000kg/h | 2-50um | 250kg | 75*38*80cm |
| JMS-130 | 380V50Hz | 11Kw | 500-4000kg/h | 2-50um | 350kg | 80*40*100cm |
Other Machines in our company:
Company Profile:
Shanghai Tiangang Machine Manufacture Co., Ltd. Integrates design, manufacture, sale and service. We specialize in manufacturing and selling soy bean machinery. Our main products are High speed grinding/separating machines, Commercial soybean Milk Machines, such as soya milk making machines, tofu making machines, dry bean curd machines, Japanese style tofu machines and related equipment.
We can offer soybean soaking & washing, auto exalting, grinding & separating, soymilk cooking & coagulating, forming & U.H.T sterilizing, cooling & packing whole systems.
We have a professional product development team and an after-sales service team. We are able to produce, install and adjust the machines, and can meet the requests of customers.
JM-80
Power supply: 380V/50Hz
Power: 4KW
Material fineness: 2-50 (um)
Output: 0.2-1.5T/h
Weight: 95kg
Size: 45*45*80cm
JM-120
Power supply: 380V/50Hz
Power: 7.5KW
Material fineness: 2-50 (um)
Output: 0.5-2T/h
Weight: 150kg
Size: 55*55*130cm
The machine mainly be suitable for comprehensive processing on ultra particles of various wet materials, such as ultra-finely grinded, emulsified, mixed, etc.
