12V 24V Power Transfer Switch 5V75W 5V15ADC-DCLED Car Power LED Display Car Power

Product Name: 12V 24V power transfer switch 5V75W 5V15ADC-DCLED car power LED Display Car

Power

Keywords: LED car power LED Display Car Power

Product Type: KREE-1224-5-75W

Color classification:

Product Details: Power Supply Model: KREE-12V24V-5V75W

Parameters Table
 Input voltage: DC12V / 24V / 36V (Wide Voltage 8.5V-40V)
 Output Voltage: DC: 5V
 Output Current: 15A
 Output Power: 75W
 Conversion rate: more than 90% Ripple: 80MV
 Working temperature: -40 ℃ ~ + 85 ℃
 Volume Specifications: 74 * 74 * 32MM (L * W * H)
 Weight: 0.3KG / a

 Baby details:

1, any one of the input voltage between 8.5V-40V wide voltage can be accurately output 5V, voltage

stability.

2, section 15A baby can work long-term, peak 25A, which means you can load device 75W or less long-

term stability without adding any heat sink. Performance is very stable, full power enough.

3, all the components are imported, synchronous rectification, aluminum alloy shell, waterproof, shock,

moisture and dust.

4. Enter the high-voltage transient protection, output overcurrent protection, output short circuit

protection, chip overheating protection.

5, for a voltage range of appliances: electric motors, audio, navigation, surveillance, LED car display, air

conditioning, fans, solar energy, photovoltaic energy, DVD, LED lights, motors, pumps, electrical

appliances and industrial equipment, and so on.

 Note Note:

 1, this section without the reverse power protection, the positive and negative input and output lines can

not be reversed, please parents who must pay attention to.
2, (remember, such as for LED car display, this power is an output, turn the power supply to the control

card, and then received a unit from the control panel of the card, you can take six monochrome (P10, P6 ,

P7.62, F3.75, F5.0 color halved) ease of use!

3, many customers are concerned with 5A, 5A power can not be used in the following equipment will burn

it?

A: No, because this power is our constant output current is adaptive output, the converter is based on your

equipment to the output current demand, as long as your device can be used in the following 5A, 5A on the

line does not exceed . Even if your device is also the same as the normal use of 0.5A contrary, the current

needs of the smaller your device, and then you choose bigger power supply actually more secure. Such

power has margin, no heat, more secure, more reliable! I hope reassure parents to buy!

4, a penny, a half a point, we must compare the performance parameters compare prices at relatively the

same time, there are a lot of car screen 10A power propaganda only real long-term work around 5V6A the

market, our power is the percentage of this 5V10A Momotari propaganda power output, which is the long-

term work to 10A output, long-term work with four cell boards, quality after-sale protection.
5, water supply, normal use, preservation six months. .
