Pellets Machine / Briquettes Machine of Carbon Black From Waste Tyre Pyrolysis Process

Pellets Machine / Briquettes Machine of Carbon Black From Waste Tyre Pyrolysis Process photo-1
US$ 48,000 - 48,000 MOQ: 12800 Sets
Key Specifications
Get Latest Price
Condition:
New
Production Capacity:
0.5-0.8T/h
Motor Type:
AC Motor
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Tianjin
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Production Capacity 0.5-0.8T/h
Motor Type AC Motor
Power(W) 15KW
Place of Origin Henan, China
Brand Name JINZHEN
Model Number JZ-400
Dimension(L*W*H) 1600*750*1650
Certification CE ISO
Warranty 1 Year
After-sales Service Provided Engineers available to service machinery overseas

Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process

Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process

This series efficient centrifugal pellet mill is our initiative patented products in China

through meticulous research and development the series pellet mill absorbs the

quintessence at home and abroad, the heart part adopts “double-layer die" as the

unique structure;



The rollers are made by abrasion-proof alloy steel, improving the using life of

spare parts greatly; For the drive parts, the grease is filtrated automatically lubricated

properly. Special design, rational structure, low power consumption, high efficiency,

sturdy and durable, supplying the gap of vertical feeding of ring-die pellet mill at home,

 reach the international advanced level.



Carbon Black Special Pellet Fuel Molding Machine Process Flow Diagram:

 Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process







The production Advantage

1. mould adopts the model hole loop, can reduce the production cost,

2. simple maintenance.

3. Low speed operation , reduce the centrifugal rate, reduce the

 temperature of die plates, improve production efficiency.

4. The equipment adopts 6.8 pole motor(960-720r/min), the greater the

diameter of the greater the output

5. Equipped with air cooled cooling, make die platers reduce temperature.

 Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process

 Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process

Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process

  • After molding, the particles are heavy, small, resistant to burn, and easy to store and transport.
  • The molded fuel’s volume is 1/30-1/40 of the raw material, weight is 10-15 times heavier than raw materials, density is 0.8-1.4, thermal value is up to 3,500-6,000 kcal.
  • The fuel is of a solid type and is easy to volatize phenol. It can replace firewood, coal, fuel oil, liquefied gas, and is widely used in heating, household stoves, hot water boilers, industrial boilers, and biomass power plants.



  • Specification

Model

Daily capacity (T/D)

Main engine power (kw)

Device configuration

HQ-300

500kg

15

Electrical cabinets,

electromotor,

forming machine

HQ-400

800kg

15

Electrical cabinets,

electromotor,

forming machine

HQ-500

1.2T

22

Electrical cabinets,

electromotor,

forming machine

HQ-600

3T

45

Electrical cabinets,

electromotor,

forming machine

Diesel version

200-400kg

28hp

Diesel, forming machine

Diesel version

400-600kg

32hp

Diesel, forming machine



The Application of Carbon Black pellet Fuel

Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process

Pellets Machine / Briquettes Machine of Carbon Black from Waste Tyre Pyrolysis Process
