Help CenterLengthwise Veneer Slicer HB35T
Related Products
-
China Professional Lengthways Wood Veneer SlicerUS$ 25,000 - 90,000MOQ: 1 Set -
HB25T Lengthwise Veneer SlicerUS$ 1,100 - 25,000MOQ: 1 Set
-
Longitudinal Veneer Slicer HB20VUS$ 1,100 - 25,000MOQ: 1 Set
-
Longitudinal Veneer Slicer HB35TUS$ 1,100 - 25,000MOQ: 1 Piece
-
Veneer Slicing MachineUS$ 30,000 - 50,000MOQ: 1 Set
Machine body:
1. Made of cast iron, ensuring work stability
2. Chromed columns, preventing wearing off
3. Well ground guideway
Key parts:
1. Swiss ABB motor or German Siemens motor that meets European latest criteria EFF2, saving power by 13%, enjoying small heating and long life span.
2. Japan-made professional slicing knife, ensuring good quality veneers.
3. Japan-made OMRON sensor to keep reliable performance.
4. AUTONICS encoder imported from South-Korea.
5. Selection of Siemens man-machine interface, convenient operation control.
6. Electric braking system independent developed by our engineers, very efficient and reliable
7. French Schneider electric
8. Italy-made professional feeding belt.
Performance:
1. Veneer output can be indicated by a counter
2. Automatic feeding speed can be adjusted by PLC
3. Veneer thickness can be from 0.5mm to 8mm according to wood harness
4. Veneer thickness error falls in ±0.05mm
Technical specification:
Name/ model |
HB 20V |
HB 25T |
HB 35T |
Max cut width |
200mm |
250mm |
350mm |
Max cut thickness |
200mm |
250mm |
350mm |
Feeding speed |
58m/min |
58m/min |
60m/min |
Total power |
12kw |
19.6kw |
33.75kw |
Overall dimension |
2420*1350*2000mm |
3360*1630*2000mm |
4600*2000*2000mm |
N.W. |
4000kg |
8500kg |
15000kg |
Welcome to visit our website: /watch?v=PGVJ2c4DfeM&feature=plcp
