Automatic High Quality Tilting Circular Saw Machine

Name: Automatic High Quality Tilting Circular Saw Machine
Brand: MIZRAK
SKU: 141508226
Availability: InStock

US$ 4,000 - 4,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Table Panel Saw

Use:

Woodworking

Qingdao Haiyong Machinery Manufacturing Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

qingdao

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Table Panel Saw

Use Woodworking

Style Horizontal

Place of Origin Shandong, China

Brand Name MIZRAK

Model Number MZK 3200 SX

Usage Wood working

Voltage 220V/380V

Power(W) 4kw

Dimension(L*W*H) 3800x800x865

Weight 800KG

Certification CE/ISO

Warranty 1year

After-sales Service Provided Overseas service center available

tilting circular saw machine

specification

Nominal Current	380 v 50hz -3p +1n 1mp
Diameter Of Outside And Inside Saw (min – max.)	Ø 250 x 30 – Ø 300 x 30
Max. Cutting Dept (90º)	80 mm
Max. Cutting Dept (45º)	70 mm
Circular Saw R.P.M.	4750 – 5250 d/d
Power Oq Saw Motor	4 kw 5,5 hp 60 hz
Table Dimensions	555x910 mm
Measure Of Disc Addet Iron Disc	800 x 400 mm
Measure Of Disc Back Iron Disc	870 x 910 mm
Measure Of Shield On Table	1200 mm
Measure Of Wandering Sledge	3800 mm
Movement Of Wandering Sledge	3800 mm
Angle Of Shield Sledge	45º
Carriage Dimension	400 mm
Measure Of Shield On Carriage	1950 mm
Supporting Of Measure Shield On Carriage	0-3000 mm
Inside And Outside Diameter Of Stripe Saw	Ø 125 xØ 20 mm
Inside And Outside Diameter Of Stripe Saw(Jumping)	Ø 200x Ø 30 mm
Power Of Stripe Saw Motor (Jumping)	0.75 kw 1 hp 50- 60 hz
Power Of Stripe Saw Motor	0.75 kw 1 hp 50- 60 hz
Total Electricity Power	4.75 kw
The Height Of The Vacuum Pipe Fort Dust	1400 mm
Lenght Machine	3800 mm
Width Machine	800 mm
Height Machine	865 mm
Net Weight Machine	800 Kg
