Specifications
1.Guide shaft spindle: 402.Addition table
3.Standard protection hood
4.Pressure board
Specifications
1.CE Approve
2.Easy to operate
3.High Precision
Basic version
Guide shaft spindle: Ø40 |
Addition table |
Standard protection hood |
Pressure board |
Manual tilting 45° |
Feature:
1. Apply to processing all kinds of density boards, shaving boards, wood-based panels, ABS panels, PVC panels, organic glass plates and solid wood and others with wood structure and similar hardness.
2. Movable table guide track is plating chromium steel bars structure, exact and durable.
3. Made of high-strength extruded aluminum alloy, movable table is high in strength and won't bend.
4. With oxidation treatment, movable table surface is beautiful and hardwearing.
Dimension of sliding table | 2200X360mm |
Gross cut capacity | 2200mm |
The biggest cutting width | 1250mm |
Saw blade diameter | 300mm(250-315) |
The biggest cutting thickness | 80mm |
Near spindle diameter | 40mm |
45°max cutting thickness | 55mm |
Speed of main saw spindle | 4000/6000rpm |
Main spindle diameter | 30mm |
Tilting saw blade | 0-45º |
Main motor | 4KW |
Diameter of scoring saw | 120mm |
Speed of scoring saw blade | 8000r/min |
Diameter of countershaft | 20mm |
Scoring motor | 0.75kw |
Overall dimensions | 2250X3150X960mm |
