paper cutting automatic knife grinder machine
Adopting the technology at home and abroad, this newly developed machine has reached the international level and has become a necessity for many knife users.
1. The working table is of electromagnetic chunk with strong magnetic power and lower consumption.
2. The spindle motor is professionally made for grinding knife, with high precision and easy maintenance.
3. The machine has a double tilting fillet to lock tight the electro-magnetic chunk, so the grinder is more stable.
4. The machine chooses rack driving, so the grinding head traveling is smoother.
5. The button is chosen from Siemens which has a reliable quality. It is easy to operate and has a long life span.
6. The switch and the contactor is choose from French Schneider electric components which are well known in the world. The quality is beyond all doubts.
7. The moving up and down of the grinding head is depended on the ball screw. The machine can use for a long time without the dropping of the knife. It is the no clearance transmission.
8. The movement of the grinding head is controlled by the inverter. Its speed is 0-20m/s. Its speed can be fitted for both accurate grinding and rough grinding.
Technical specifications:
Name/ model | HM1815 | HM1822 | HM1830 | HM1835 | HM1842 | HM1870 |
Max grinding length | 1500mm | 2200mm | 3000mm | 3500mm | 4200mm | 7000mm |
Width of the working table | 180mm | 180mm | 180mm | 180mm | 180mm | 180mm |
Grinding head power | 4kw | 4kw | 4kw | 4kw | 4kw | 7.5kw |
Linear speed of grinding wheel | 15m/s | 15m/s | 15m/s | 15m/s | 15m/s | 15m/s |
Speed of the sliding plate | Stepless speed change | Stepless speed change | Stepless speed change | Stepless speed change | Stepless speed change | Stepless speed change |
Tilting range of the working table | ±90° | ±90° | ±90° | ±90° | ±90° | ±90° |
we mainly have three kind of knife grinder,this is video:
Standard steel guide knife grinder /watch?v=NCQMXHLEcXk
linear guide knife grinder: /watch?v=RgVjfyQ1Ndk&feature=plcp
CNC knife grinder: /jzxiaozhi?v=EsxiiD9w8I4
we have some other knife grinder for special purpose,if you want others or if you want more informatin and videos for reference,please contace me,i will suggest you the suitble machine.
