Specifications
1.Gluing,End cuffing2.Fine trimming
3.Scraping,Buffing
New type of banding machine high-tech, lengthened machine body . Functions automatic feeding ,gluing ,end trimming, fine finishing ,rotaating scraping, polishing. Highlight: nover construction, sstable performance,easy operation. Frequency conver for fifferent kinds of banding.
Progress: pre-heating , gluning, end reimming, rough funishing, fine funishing, polishing .
Basic function: workpiece conveyance, gluing banding , press banding and cut off, end trimming, fine finishing the eddge, edge scraping ,polishing , frequency converter regulates worrking speed.
Function:1.Gluing,End cuffing 2.Fine trimming 3.Scraping,Buffing
Main configuration:LG electric,DELTA Inverter,DELTA Touch screen,Parker cylinder,DKC Electromagnetic valve
Main technical parameter for HY365 | |
Motor Power |
8kw |
Ocerall Size(Long&Width&High) |
4140mm×1000mm×1600mm |
Feed Speed |
12-20m/min |
Panel Thickness |
10-60mm |
Edge Thickness |
0.4-3mm |
Panel Width |
≥80 |
Working Pressure |
0.6MPa |
