Specifications
Waste Oil Refinery to Diesel Oil Equipment with CE.SGS.ISO. high effiency
. zero pollution&safety
. 4 vertical condensers
Waste Oil Refinery to Diesel Oil Equipment with CE.SGS.ISO
Main Parts of Waste Oil Refinery to Diesel Oil Equipment with CE.SGS.ISO
Advantage
1> Security: a. Adopting automatic submerged-arc welding technology
b. All of the weldings will be detected by the ultrasonic nondestructive testing method to ensure the welding quality and the welding shape.
c. Adopting manufacture process controlling system on the quality, every manufacture process, manufacture date, operators, etc.
d. Equipped with anti-explosion device, safety valves, emergency valves, pressure and temperrature meters, vacuum pump, as well as the alarming system
2> Environmental-friendly: a. Emission Standard: Adopting special gas scrubbers to remove acid gas and dust from smoke
b. Smell during operation: Fully enclosed during the operation
c. Water pollution: No pollution at all.
d. Solid pollution: the solid after pyrolysis is the crude carbon black and steel wires which can be deep-processed or sold directly with its value.
3> Energy conservation and low cost on operation: .Special covers of the reactors and chambers can keep hot during the heating in good efficiency as well as the direct heating system to save energy and cost. 4> Output of the oil Our distillation plant can output diesel oil 80-90 %.
|
The Reactor
The Clarming System
Technology Parameter of Waste Oil Refinery to Diesel Oil Equipment with CE.SGS.ISO | ||
NO | ITEM | PROJECT |
1 | Suitable raw materials | Waste engine oil, pyrolysis fuel oil, crude oil |
2 | Structure | Horizontal type |
3 | Capacity(24 hours) | 3.5~6.5 tons |
4 | Work pressure | Normal pressure |
5 | Oil yield | 85%-95% |
6 | Power | 12KWH |
7 | Cooling method | Cycle water |
8 | Condensers | 4 pieces of vertical condensers |
9 | Emission treatment | New de-sulfurization smoke scrubbers |
10 | Heating method | Hot air |
11 | Type of installation | With foundation |
12 | Noise dB (A) | Less than 85 |
13 | Dimension of reactor | 2200*6000mm/2500*8800mm |
14 | Operating mode | Semi-continuous operation |
15 | Main chamber weight | 10-13 tons |
16 | Total weight | 25-35 tons |
17 | Installation space required | 35m*15mm |
18 | End product | Non-standard diesel oil |
19 | Manpower | 1~2/shift |
20 | Shipment requirement | 1*40HC+1*40FR |
The Flow Chart
Coutries exported to:
We have been exported to USA,Saudi Arabia,New Zealand,Australia,Poland,Malaysia,India,Pakistan,Thailand,Vietnam,
Indonesia,South Africa,Korea, Bangladesh,Mongolia etc.
After Sales Service
.Quality warranty period: One year warranty for the chamber of the distillation machines,and lifetime maintenance
for complete set of machines. pay the double air tickets, accommodation and food.
.According to the requirement of the buyer, our company sends engineers for installation and commissioning in buyer's site including the training of skills of buyer's workers on operation, maintenance, etc.
. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the
buyer.
. For the damage caused by the users, our company provides the parts and accessories with cost price.
.Our factory supplies the wearing parts with the cost price to clients.
Our Certificate
