Crude Oil and Used Oil Recycling Equipment with SGS.ISO
The Description of distillation Plant
The Features of Distillation Plant
|
..Unique and original manufactureing and technology with our formula of our equipments in china. ..Unique horizontal design,high oil output with about 90% oil yield and 100% conversion rate,highly effective and profitable. ..Good quality end products oil as the substitution of standard diesel oil in usage. ..Automatic Submerged welding technology,ultrasonic nondestructive testing,both manual and the automatic safety devices. ..Sync Gas Recycling System:Fully burned after recycling and utilization,saving fuel and preventing pollution. ..National Patent,unique heat insulation shell;high efficiency temperature keeping,excellent energy-saving effect. ..High condensing efficiency condensers with more oil output.Good quality oil,Longer lifetime,and easy to clean. ..National Patent water film Smoke Scrubbers;Efficient removal of the acid gas and dust of the smoke,environmental friendly to meet related national standards. |
The Flowchart
The Distillation Chamber
The Distillation Column
Condensers
Oil Tank
Sync Gas Recycling System
Technical Parameter of the Horizontal Diatillation Plant | |||
NO. | ITEM | PROJECT | |
1 | Equipment Mode | XY-1 | |
2 |
Suitable Raw Materials | Waste engine oil,fuel oil,crude oil | Waste engine oil,fuel oil,crude oil |
3 | Strcture | Horizontal type | Horizontal type |
4 | Capacity(24h) | About 3~4Mt | About 5~6Mt |
5 | Work pressure | Normal pressure | Normal pressure |
6 | Oil yield | 85%-95% | 85%-95% |
7 | Power | 12kw/h | 12kw/h |
8 | Heating Method | Hot air | Hot air |
9 | Type of Insstallation | With foundation | With foundation |
10 | NoisedB(A) | <=85 | <=85 |
11 | Reactor size | 2200*6000mm | 2500*8800mm |
12 | Operating mode | Semi-continuous Operation | Semi-continuous Opreation |
13 | Cooling method | Water recycling | Water cycling |
14 |
Condensers | 3pieces of Horizontal Condensers | 3pieces of Horizontal Condensers |
15 | Installation Space required | 30m*12m | 35m*15m |
16 |
End product | Non-standard Diesel oil | Non-standard Diesel oil |
17 | Manpower | 1~2/shift | 1~2/shift |
About us
Shangqiu JinYuan Machinery Equipment Co.LTD.,is the first domestic professional institute in the recycling and utilization
of solid wastes (waste plastic,waste tyre,rubber).
Our company has developed XYSeries environmental protection equipments.Up to now, our products include Pyrolysis
Plants for waste rubber,plastic and tyres,normal or negative pressure. Distillation Plants for waste engine oil,pyrolysis fuel
oil,crude oil and the Carbon Black Deep-process Machines.
We has owned 14 national patents .Our comany also has achieved CE,SGS,ISO,BV,BUV certificates.The emission can
meet GB13271---2001 related standards.
AFTER SALES SERVICE
1.Quality warranty period: One year warranty for the chamber of the distillation machines,and lifetime maintenance for
complete set of machines. pay the double air tickets, accommodation and food.
2.According to the requirement of the buyer, our company sends engineers for installation and commissioning in buyer's
site including the training of skills of buyer's workers on operation, maintenance, etc.
3. Supply layout according to buyer's workshop and land, civil works information, operation manuals, etc. to the buyer.
4. For the damage caused by the users, our company provides the parts and accessories with cost price.
5. Our factory supplies the wearing parts with the cost price to clients.
Successful Installation
