Specifications
Ceramic rod flame spraying,ceramic rodsGood electrical insulator
Very good abrasion resistance
Good thermal shock resistance
Kingsky™ A KS-02, Aluminum Oxide Ceramic Rod, Ceramic Rod Flame Spraying : rokide flame spray unit
• Vailable Rod Size
Kingsky™ A KS-02 1/4" Diameter x 24"
Diameter: 1/4"± 0.0012" (6.35mm±0.03mm ) Length: 24" ~24.4" (610mm~620mm)
• Properties
Good Electrical Insulator
Very Good Abrasion Resistance
Good Thermal Shock Resistance
• Typical Chemical Composition(%)
AI2O3 98.42
SiO2 0.80
TiO2 0.01
CaO 0.12
NaO2 0.31
Fe2O3 0.04
MgO 0.30
• Color and Weight
Color: White
Weight: 48-50g/pcs
• Hardness & Thickness
Hardness: HV1000~1200
Coating Thickness: 0.12mm - 3 mm
• Applications
Mechanical Seal Faces
Ceramic Furnace Trays
Entry guide vanes
• Coating Features
Deposit Efficiency: 72%~80%
Total porosity: <13%
Bulk Density: 3.1g/cc
Coating Hardness: HV1100
Melt Temperature : 2800 ℃
Kingsky™ A 1/4" (KS-02);
Rods Packaged in Tubes: 50 rods;
10 tube per wooden box: 500 rods
Worth knowing:
Properties of Aluminum Oxide Ceramic (Al2O3)
•Very good electrical insulation (1x1014 to 1x1015 Ωcm)
•Moderate to extremely high mechanical strength (300 to 630 MPa)
•Very high compressive strength (2,000 to 4,000 MPa)
•High hardness
•Moderate thermal conductivity (20 to 30 W/mK)
•High corrosion and wear resistance
•Good gliding properties
•Bioinert and food compatible
Ceramic Rod Flame Spraying
Products spray by Aluminum Oxide (Al2O3)
Numerous chemistries are available, each offering unique advantages. Aluminum oxide coatings can be engineered to improve dielectric performance (using nearly-pure AlO3), to provide electrical insulation, to boost corrosion or wear resistance (using titanium oxide additives), to reduce or eliminate current transfer arc erosion, and more, based on customer requirements for part performance
•Ball Heads
•Ballistic Protection Components
•Bearing Technology in Automotive Engineering
•Drawing Tools
•Dry-pressed Substrates (Ceramics)
•Vacuum Isolators
•Metalized Substrates (Ceramics)
•Protective Ceramics (Ballistics)
•Pumps, Components for
•Seal and Regulator Discs
•Seal Rings, Bearings and Sealing
•Sealing Technology (Seal Rings, Bearings)
•Stamped Substrates (Ceramics)
•Textiles Industry
•Vacuum Accessory Components
•Wear Protection, Components for
•Wire Drawing, Components for
rokide flame spray unit
