♦ Application field
Suitable for food, cosmetics, paper, paint, chemicals, pharmaceuticals, textiles, fuel thermoelectric, fuel central air conditioning, petroleum, metallurgy, biodiesel and many other industrial processes .
1. Herbal medicine extraction, cells, bacteria, viruses, tissue crushing, such as extraction of cell contents.
2. The material particles dispersed, homogenize, and emulsions. For example, the dispersion of nanometer
materials, cosmetics emulsion.
3. Accelerated dissolution, accelerate chemical reactions, such as chemical synthesis.
♦ Adventage of Biodiesel
BANRY Ultrasonic Biodiesel Reaction is composed of ultrasonic transducer (converter) with cover , booster , horn ( sonotrode , probe ) and generator .
♦ Principle of Ultrasonic Biodiesel Reaction - Acoustic Cavitation
Ultrasonic in the liquid produced hundreds of thousands of times per second, make the liquid to break into tiny bubbles of vibration, these bubbles in the role of the continuous, rapid growth, then suddenly closed, produce the super shock wave, around the bubble produced thousands of atmospheres of pressure and local high temperature, the physical phenomenon known as ultrasonic cavitation effect.
| Brand / Product | BANRY / Sonochemistry Processor | |||||
| TYPE | BR-28SH | BR-20SH-5 | BR-20SH-10 | BR-20SH-15 | BR-20SH-20 | BR-20SH-30 |
| Frequency | 28kHz | 20 kHz | ||||
| Max. power | 200W or 500W | 500W | 1000W | 1500W | 2000W | 3000W |
| Handing Capacity (L/h) | ≤500 | ≤500 | ≤800 | 200-1000 | 300-1600 | 1600-2500 |
| Apply | laboratory | Production line , can be used in combination | ||||
| Allow pressure | Max≥5 MPa | |||||
| Allow temperature | Max≥350°c | |||||
| Generator | Digital generator can be adjusted the output amplitude from 50% to 100%, frequency tracking automatically to sure working continuously | |||||
| Cable | Standard 5m Special length, please inform us | |||||
BANRY Ultrasonic 's processing cycle = Traditional way's processing cycle / 20
Hangzhou Banry Ultrasonic Focus on the domestic first high-power ultrasonic probe ultrasonic sonochemistry processing equipment. Does not change a customer's existing production equipment and technological process, through a simple installation can be your ordinary equipment upgrades for the chemical industry with the advanced ultrasound equipment. Ultrasonic high-power, and low investment, simple installation, output and efficiency was improved.
Ultrasonic technology has a prominent advantages, that is, it does not have moving parts, there is no electromagnetic radiation, is simple to install fixed, in particular for the high-pressure high-temperature, toxic, explosive or dangerous environment for the application.
1. Optional frequency and power, 40kHz — 20 kHz , 200W - 3000W .
2. Withover current , overvoltage protection ,to ensuresystem security .
3. Frequency automatic tracking adjustment , to avoid the load impedance with the ambient temperature , the working medium due to factors such as changes in the larger power fluctuations.
4. Constant power , good effect .
5. Ultrasonic digital generator , small size , light weight and high efficiency .
6. Reasonable structure , easy ventilation , continuous running and reliable operation.
Modular design , can be by several hundred watts or several kilowatts of power to form tens kilowatts generator , which can optimize the combination of the transducer, and then ensure transducer work in the best condition; such as a generator fails, the other unitstill work , easy to repair the damaged unit .
♦ After-sale Service
Please click the following pictures to see your interesting products details :
Hangzhou BANRY BANRY 28kHz 20kHz Ultrasound Ultrasonic biodiesel oil machine
