Limestone burning machine of lime rotary kiln for lime production line
- 20 Set / Sets per Month
- Qingdao Shanghai Tianjin Lianyungang
- T/T Credit Card
Product Details
Condition: | New | Production Capacity: | 20t/h | Place of Origin: | Henan, China |
Brand Name: | Derui | Model Number: | Y-4060 | Voltage: | 380v |
Power(W): | 315kw | Dimension(L*W*H): | 4*60m | Weight: | 480t |
Certification: | ISO | Warranty: | one year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Limestone burning machine of lime rotary kiln for lime production line
For lime production line, main equipment needed:
1.Preheater
2.lime rotary kiln
al mill
4.dust collector
al burner
oler
7.bucket elevator
8.Vibarting screen
Limestone introduction:
Limestone is a sedimentary rock composed largely of the minerals calcite and aragonite, which are different crystal forms of calcium carbonate (CaCO3).
It is the raw material for the manufacture of quicklime (calcium oxide), slaked lime (calcium hydroxide), cement and mortar.
Lime rotary kiln introduction :
Limestone rotary kiln is mainly used for heating and calcining various mineral materials in metallurgy, construction, and ores etc, such as ceramsite sand, bauxite, limestone, cement, metal magnesium, alumina, hydroxide alumina, fly ash , high aluminum refractory materials, etc.
Lime rotary kiln technical parameter:
Model(m) | Diameter (m) | Length(m) | Slope(%) | Capacity(t/h) | Rotate Speed (r/min) | Motor Power(kw) | Weight(T) |
φ1.4×33 | 1.4 | 33 | 3 | 0.9-1.3 | 0.39-3.96 | 18.5 | 47.5 |
φ1.6×33 | 1.6 | 33 | 4 | 1.2-1.9 | 0.26-2.63 | 22 | 50 |
φ1.6×36 | 1.6 | 36 | 4 | 1.2-1.9 | 0.26-2.63 | 22 | 52 |
φ1.8×32 | 1.8 | 32 | 4 | 1.9-2.4 | 0.16-1.62 | 30 | 78.2 |
φ1.8×45 | 1.8 | 45 | 4 | 2.8-3.34 | 0.21-2.11 | 30 | 95.2 |
φ1.9×36 | 1.9 | 36 | 3.5 | 1.2-1.7 | 0.29-2.93 | 30 | 86.3 |
φ1.9×45 | 1.9 | 45 | 3.5 | 1.65-2.5 | 0.29-2.93 | 37 | 109 |
φ2.2×48 | 2.2 | 48 | 3 | 1.9-2.1 | 0.98-2.93 | 55 | 141 |
φ2.5×40 | 2.5 | 40 | 3.5 | 6.0-7 | 0.44-2.44 | 55 | 139.61 |
φ2.5×50 | 2.5 | 50 | 3.5 | 7.0-8.0 | 0.48-1.44 | 55 | 179.6 |
φ2.5×54 | 2.5 | 54 | 3.5 | 8.0-8.6 | 0.48-1.44 | 55 | 196.29 |
φ2.7×42 | 2.7 | 42 | 3.5 | 10.0-11.0 | 0.10-1.52 | 55 | 198.5 |
φ2.8×44 | 2.8 | 44 | 3.5 | 11-12.5 | 0.80-2.39 | 55 | 198.6 |
φ3.0×45 | 3 | 45 | 3.5 | 13.3-16.9 | 0.5-1.35 | 55 | 223 |
φ3.2×52 | 3.2 | 52 | 3.5 | 16-18.5 | 0.48-2.44 | 110 | 278 |
Lime rotary kiln for lime production:
Lime production process:
Raw material feeding
The limestone/dolomite in the plant yard will be carried by tractor shovel and feed to hopper, it will be discharged from hopper to vibrating feeder and sent to vibrating screen for screening through belt conveyor.The size >20mm will be send to pre-heater by conveyor. And size less than 20mm will be carried away.
Calcination
The limestone/dolomite in the preheater will be preheated by the hot air, then it will be discharged to rotary kiln through chute that connecting preheater and kiln, it will stay in the kiln for 1.5-2 hours for calcination, during the process, it will be calcined with the temperature around 1300 degree, limestone decomposition, release of CO2, become quick lime. then lime moves to vertical cooler for cooling.
lime/calcined dolomite conveying
Lime will be discharged to a chain conveyor by vibrating feeders in the bottom of vertical cooler, it will be lifted to storage hopper by bucket elevator. So the lime in the storage hopper for dispatch.
Dust filtering
There are two dust filtering system, one is in the kiln inlet, dust will be filtered by bag filter then the clean gas will be release to air.
Application of Lime rotary kiln :
It can be used in building materials, metallurgy, chemical industry, cement plant for drying of limestone slag, coal powder, slag, clay stone,etc.
Derui Intorduction:
Derui machinery Co., Ltd. is a China-based high-technology heavy machinery manufacturer, which engaged in R&D, production and sales of machinery. Our main products include mill grinding machine, rotary kiln, mineral processing equipment, dryer equipment, stone crusher machine, sand and stone production line.
Rotary kiln equipment:cement rotary kiln, lime rotary kiln, ceramsite sand rotary kiln, metallurgy rotary kiln, bauxite rotary kiln, etc.
How to visit us ?
If you want to visit our factory, please note our city name, Zhengzhou City, Henan Province, China(mainland)
Our air port name is : Zhengzhou Xinzheng International air port.
Train station name is: Zhengzhou (Zhengzhou north) train station
