Home > Products > New Products > 2016 China woodworking machine MC1352/2 two side hydraulic composer series
2016 China woodworking machine MC1352/2 two side hydraulic composer series
- 100 Set / Sets per Month
- Qingdao Shanghai Guangzhou or as your requirements
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Type: | Other, hydraulic composer series | Place of Origin: | Shandong, China |
Brand Name: | STEELER | Model Number: | MC1352/2 | Voltage: | 380V |
Power(W): | 5.5kw | Dimension(L*W*H): | 5600*2300*2250mm | Weight: | 5500-6500kg |
Certification: | CE ISO | Warranty: | One Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
2016 China woodworking machine MC1325/2 two side hydraulic composer series
Properties:
1. It is featured by stable movement, large pressure and uniform pressing by adopting the hydraulic principle, and can prevent reverse warping by exerting pressure above or in front of workpiece, making gluing of laminated timber flat and perfect.
2. A pressure maintaining or supplementing mechanism in the hydraulic system provides continuous gluing pressure and is good for improvement of quality.
3. Presser feet in the front can move left and right entirely according to specifications of workpieces.
4. A-shaped clamp carrier has two working faces, each of which can operate independently,
enjoying high efficiency and safe and reliable operation.
Characteristics:
1.This machine adopts hydraulic principals characterized by a stable motion speed,huge pressure and still pressing.High density braced sheeting as back worktop and pressure from the above
and front can prevent the curved angle and make the board glued completely.Low sanding and high output.
2.According to different working specifications(length or thickness),system pressure can be
adjusted according to different pressure required.And there is pressure-supplement system,
which ensure the continuous pressure.
Technical parameters:
Model | MC1352/2 |
ing length | 5200mm |
ing width | 1300mm |
Working thickness | 10-150mm |
Top cylinder dia. | 80 |
Toy cylinder amounts of each side | 10/12 |
Side cylinder dia. | 40 |
Side cylinder amounts of each side | 10/12 |
Lift cylinder dia. | 63 |
Lift cylinder amounts of each side | 2/4/6 |
Motor power for hydraulic system | 5.5kw |
Rated pressure of system | 16Mpa |
Overall dimensions(L×W×H) | 5600×2300×2250mm |
Weight | 5500-6500kg |
The products detail:
1.ShippingWe have rich experience in exporting machines to the world and can supply all kinds of different shipping terms!
2.Timely delivery and transportation.
We have years of manufacturing woodworking machine.OEM and ODM service available.
Sample Service :
If you want to test the performance of machine ,we can sent sample to you with cost offer.
Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
After-sale Service:
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Engineers available to service machiner overseas.
Qingdao Steeler woodworking machinery co.,ltd is the professional production of various kinds ofsanding machine,polishing machine and other mechanical equipment manufacturers.The company
produced sanding machine which is a combination of Germany,Italy,Taiwan's good mechanical
properties,structure and the advanced polishing machine not only draw lessons from the foreign
advanced technology,and highlights the Steeler people development innovation,enterprising spirit,continuous research and development to adapt to the market,make our polishing machine seriesequipment industry's leading edge products.
