Four head drilling machine MZB73224 made in china
Max.drill dia | 35mm |
Max.boring depth | 60mm |
Max dimensions of pieces to be drilled | 2800x752x80mm |
cessing length of vertical head | 2800mm |
cessing length of horizontal head | 2450mm |
Max.distance of the two horizontal heads | 752mm |
Min length between vertical spindle heads | 140mm |
Numbers of spindle | 22*4 |
Spindle speed | 2840r/min |
Installed power | 1.5kw×2,1.1kw×4 |
Air pressure | 6-8kg/cm² |
Suitable voltage | 380V 50HZ |
Min center distance between spindles | 32mm |
Gas consumption for drilling ten panels per min | 11L/min |
Overall size | 3800*2500*1500mm |
Net weight | 2000kg |
1.Packing Details:Stretch film with wooden case or as your request .
2.Shipping: We have rich experience in exporting machines to the world and can supply all kinds of different shipping terms!
3.Timely delivery and transportation!
1.Good after-sale Services is our strength
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Our engineers can provide services to overseas.
2.Main Market
Which have been exported to a lot of country and Regions . Such as Europe , Russia, Southeast Asia . Middle East . North America
and south America , Australia .
3.Sample Service :
If you want to test the performance of machine ,we can sent sample to you with cost offer .
4.Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
5.We have years of manufacturing woodworking machine,OEM and ODM service available.
1) Q: What's the MOQ?
A: MOQ is one set.
2) Q: Provide custom machine Yes or No?
A: Yes. We can provide custom machine for clients.
3) Q: What's the payment terms?
A: T/T 30% in advance and balance before shipment or by negotiation.
4) Q: Are you factory or trade company?
A: We are factory and trade company. STEELER is our brand.
5) Q: How long is the warranty period?
A: One year warranty period except the quick-wear parts.
6) Q: Do you have professional engineers?
A: Yes. We have professional engineers and designers. We can provide OEM products.
