Wood machinery WP2500 Positive and negative vacuum membrane press machine for curve board
Item |
WP2500 |
Interior working table size |
2500x960 |
Maximum processing thickness(mm) |
50 |
Vacuum pressure(mpa) |
negative pressure-0.09Mpa positive pressure0.3Mpa |
Power source(w) |
380V.50HZ |
Total power(kw) |
24kw |
Current consumption |
11kw |
Overall dimension(LxWxH)mm |
2900x1350x2150mm |
Net weight(t) |
3500kg |
Max temperature |
140℃ |
This series of equipment is designed for manufacturing room doors and cupboard paltes,which can be used to filming the veneer for door panels.The WP2500 machine can realize many functions(cold and hot pressing machine ,filming single side or double sides of solid wood door plates,and filming PVC doors).The equipment can gluing PVC workpiece firmly together,do not bounce and wrap.When manufacturing nonpainted door,which can cutting PVC size the same as the door size,to save the PVC film.
1.Good after-sale Services is our strength
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Our engineers can provide services to overseas.
2.Main Market
Which have been exported to a lot of country and Regions . Such as Europe , Russia, Southeast Asia . Middle East . North America
and south America , Australia .
3.Sample Service :
If you want to test the performance of machine ,we can sent sample to you with cost offer .
4.Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
5.We have years of manufacturing woodworking machine,OEM and ODM service available.
1) Q: What's the MOQ?
A: MOQ is one set.
2) Q: Provide custom machine Yes or No?
A: Yes. We can provide custom machine for clients.
3) Q: What's the payment terms?
A: T/T 30% in advance and balance before shipment or by negotiation.
4) Q: Are you factory or trade company?
A: We are factory and trade company. STEELER is our brand.
5) Q: How long is the warranty period?
A: One year warranty period except the quick-wear parts.
6) Q: Do you have professional engineers?
A: Yes. We have professional engineers and designers. We can provide OEM products.
