High Quality Wood Saw Machine MJ1435D Muli-blade Round Sawing Machine

Technical parameter:

1.This machine uses upper and lower power roller,driven by worm gear speed reducer,and actuated by universal joint to ensure feeding smooth and strong.
2.Upper feeding roller controlled by pressure air cylinder,and you can free to adjust according to the hardness of the timber.
The feeding speed is Frequency conversion control,the viewable digital display shows the feeding speed,easy to understand.
The laser marker instrument indicate the blade position accurately.
Protective device for elevation of saw blade can safety limit with the lifting feeding roller and saw blade,to prevent the damage from misopearation.
3.The special design,making the across bridge plate is no longer have to process comlicated dovetail chute.
4.Special alloy steel material used for the saw shaft, through multiple times of heat treatment and a special process with precision.
5.The special designed blade cooling device,the atomizated cooling liquid can direct spary to the blade,thereby increase the service life of the saw blade.
6.The upper and lower non-return device to prevent the wood chips rebound.
7.Feeding roller has a sawdust removal device which can remove the sawdust adhere to the deeding roller surface quickly,to ensure smooth feeding.
8.Concentrated lubricated system directly supply lubricating oil to lifting column,the feeding roller arm,dovetail guide,the swing shaft of the motor plate.Each shift operator simply shake the handle, the lubricating will be transpoted to all parts,so maintenance is simple and easy.
9.The pulley uses keyless structure,and it easy to complete installation and maintence

Detail:

1.Packing details: Stretch film with wooden case or as your request.

2.Shipping:We have rich experience in exporting machines to the world and can supply all kinds of different shipping terms.

3.Timely delivery and transportation

1.Good after-sale Services is our Superiority

1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.

4) Oversea engineer after-sale service is available.

2.Main market

Our products has been exported to all over the word, including North America, EU countries, Austrilia, Southeast Asia, Africa and Latin America.

3.Sample Service

If you want to test the performance of machine ,we can sent sample to you with cost offer.

4.Customized Service

Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.

5.We have years of manufacturing woodworking machine, OEM and ODM service are available.

Qingdao Steeler woodworking machinery co.,ltd is the professional production of various kinds of sanding machine,polishing machine and other mechanical equipment manufacturers.

The company produced sanding machine which is a combination of Germany,Italy,Taiwan's

good mechanical properties,structure and the advanced polishing machine not only draw lessons from the foreign advanced technology,and highlights the Steeler people development innovation,

enterprising spirit,continuous research and development to adapt to the market,make our

polishing machine series equipment industry's leading edge products.

1) Q: What's the MOQ?
A: MOQ is one set.
2) Q: Provide custom machine Yes or No?
A: Yes. We can provide custom machine for clients.
3) Q: What's the payment terms?
A: T/T 30% in advance and balance before shipment or by negotiation.
4) Q: Are you factory or trade company?
A: We are factory and trade company.
5) Q: How long is the warranty period?
A: One year warranty period except the quick-wear parts.
6) Q: Do you have professional engineers?
A: Yes. We have professional engineers and designers. We can provide OEM products.
