MFB503 edge bander woodworking machine edge banding machine
Application:
1.Gluing&edging unit adopt lower glue tank,whole screwy feeding unit,to make feeding glue conveniently and equally.
2.Fine trimming unit to trim the exceeding edge on the top and the bottom side of the panel.It is completed with two motors and copying .
3.Buffing unit to clean the edge of the finished panel,it is completed with two independent motors and two cotton polishing wheels.
The Technical Data:
Panel thickness |
10-50mm |
Edging thickness |
0.4-3mm (PVC) |
Min.width of panel |
>=60mm |
Belt height |
12-50mm |
Panel feeding speed |
<=18m/min |
Pneumatic power |
0.7Mpa |
Power |
380V 3N/PE 50HZ |
Panel feeding motor |
1.1kw 50HZ |
Glue axis motor |
0.75kw |
Fine trimming motor |
0.5kwx2 200HZ 12000r/min |
Buffing motor |
0.18kwx2 50HZ 1400r/min |
Heating power of glue tank |
2.6kw |
Secondary heating power |
0.12kw |
Installed power |
6.43kw |
Glue temperature for edging(reference) |
180-200°C |
Overall dimensions |
2420x1400x1400(mm) |
Weight |
850kg |
The Product Detail:
The Packaging and Shipping:
We have years of manufacturing woodworking machine.OEM and ODM service available.
Sample Service :
If you want to test the performance of machine ,we can sent sample to you with cost offer.
Customized Service :
Our factory has been specialized in producing woodworking machines for over 33 years .We have very high research and development capabilities to meet the requirements of custom.
After-sale Service:
1) The machine guarantee is 12 months.
2) 24 hours technical support by email or calling.
3) Friendly English version manual and operation video CD disc.
4)Engineers available to service machiner overseas.
Qingdao Steeler woodworking machinery co.,ltd is the professional production of various kinds of sanding machine,polishing machine and other mechanical equipment manufacturers.
The company produced sanding machine which is a combination of Germany,Italy,Taiwan's
good mechanical properties,structure and the advanced polishing machine not only draw lessons from the foreign advanced technology,and highlights the Steeler people development innovation,
enterprising spirit,continuous research and development to adapt to the market,make our
polishing machine series equipment industry's leading edge products.
