30Ton hot selling flour mill roller
1. clean part
Includes beating, screening, destoner, magnetic separator and dampening. Different capacity machine line has different number of beat, screen and destoner.
1.1 Beating: through the beat function of the wheat scourer, brusher to remove dust sand small seed, bacterial count and insect seed.
1.11 wheat scourer
Technical Parameter:
| Technical Parameter |
Drum Diameter (mm) |
Drum Length (mm) |
Speed (mm) |
Capacity (T/H) |
Power (KW) |
Weight (KG) |
L*W*H (mm) |
| FDMWA30*60 | Φ300 | 600 | 650-780 | ≤12 | 7.5-15 | 760 | 1220*600*1615 |
| FDMWA45*80 | Φ450 | 800 | 437-520 | 12-25 | 15-22 | 980 | 1460*800*1876 |
1.2 Screening: to remove large and small impurities in the wheat seed by make the wheat go through vibrating sieve and aspiration sieve.
1.3 Destoner: mainly remove stone in the wheat to prevent them milled into the flour and also protect the roller on the milling process.
Technical Parameter:
| Technical Parameter |
Screen Width (cm) |
Capacity (T/H) |
Air Pressure (Pa) |
Air Volume (m3/h) |
Swing (mm) |
Screen Leaning Angle(°) |
Power (KW) |
Swing (time/min) |
Wt (KG) |
Size (mm) |
| TQSF43 | 43 | 1-1.5 | <980 | 3000 | 4-5 | 5-9 | 2*0.25 | 960 | 215 | 1270*700*1600 |
| TQSF50 | 50 | 2-4 | <980 | 4000 | 4-5 | 5-9 | 2*0.25 | 960 | 230 | 1420*780*1800 |
| TQSF60 | 60 | 3-5 | <980 | 4500 | 4-5 | 5-9 | 2*0.25 | 960 | 280 | 1450*876*1800 |
| TQSF80 | 80 | 5-7 | <980 | 6000 | 4-5 | 5-9 | 2*0.25 | 960 | 340 | 1450*1046*1800 |
| TQSF100 | 100 | 7-9 | <980 | 8000 | 4-5 | 5-9 | 2*0.25 | 960 | 400 | 1500*1246*1900 |
| TQSF125 | 125 | 9-11 | <980 | 10200 | 4-5 | 5-9 | 2*0.25 | 960 | 500 | 1470*1496*1900 |
| TQSFB125 | 125 | 15-18 | <980 | 12000 | 4-5 | 5-9 | 2*0.55 | 960 | 650 | 1649*1714*2083 |
| TQSF150 | 150 | 11-14 | <980 | 12000 | 4-5 | 5-9 | 2*0.25 | 960 | 600 | 1580*1746*1900 |
| TQSFB150 | 150 | 18-20 | <980 | 15000 | 4-5 | 5-9 | 2*0.55 | 960 | 760 | 1649*1964*2083 |
| TQSF175 | 175 | 14-18 | <980 | 15000 | 4-5 | 5-9 | 2*0.25 | 960 | 750 | 1470*1990*1900 |
| TQSF200 | 200 | 16-20 | <980 | 17000 | 4-5 | 5-9 | 2*0.25 | 960 | 1000 | 1470*2292*1900 |
| TQSF250 | 250 | 20-22 | <980 | 204000 | 4-5 | 5-9 | 2*0.25 | 960 | 1050 | 1470*2835*1900 |
1.4 Magnetic separator: remove metal material in the wheat to keep the roller safe and also avoid flour explosion accident of spark caused by the impact of the metal impurities and the machine.
1.5 Dampening: dampening the wheat bran before mill to ensure the bran’s integrity during the milling processing, avoid the bran going into the flour to keep flour quality.
2. Milling part
Include different number of mill and sifter to mill the wheat and separate the flour and bran.
(1) Mill: mill the wheat to break the integrity by the roller moving
(2) Sifter: to separate the flour and bran, also separate large size and small size to ensure flour quality.
3. Packing part of
The packing part can be manual also can be auto, this can be designed according to requirement and machine capacity.
4. Parameters
| Model | LF-10 | LF-20 | LF-30 | LF-40 |
LF-50 |
LF-60 |
LF-80 |
LF-100 |
|
Capacity (Ton/day) |
10 | 20 | 30 | 40 | 50 | 60 | 80 | 100 |
|
Main machine dimension (L*W*H)(M) |
14*7.5*6 | 16*7.5*6.5 | 18*7.5*7 | 22*7.5*7 | 24*7.5*7 | 30*8*12 | 33*8*12 | 33*10*12 |
|
Total power (KW) |
56 | 86 | 94 | 131 | 144 | 223 | 327 | 340 |
Henan Maosheng Group was founded in 1976, after nearly 40 years of development and growth, has become a well-known Chinese grain and oil machinery manufacturing enterprises with import and export rights, in 2002 passed the ISO9001 quality management system certification, National Food Processing Equipment Engineering Technology Research Center, the National agro-processing technology and equipment research and development sub-centers and the provincial post-doctoral research base development platform
.
More information ,pls contact as follows:
