black soybean hull extract powder machine for making soya oil
1.We undertake pre-treatment, pressing, extraction, oil refining and the auxiliary projects, the services include civil negineering, process design, auto-control, layout plan and the cereals and oils further processing, ybean phospholipids, proteins, rare and high-value oils. In addition, we undertake process design and construction of feed mill, wheat flour plants.
2. 10-500T/H oil material first cleaning,drying and storage section turn-key project.
3.100-3000 T/D oil pretreatment, shelling and pre-press workshop turnkey project (soybean hot peeling, bean skin crushing; the soybean extrusion, high oil contained pre-press cake extrusion, and high oil contained embryos puffed; of direct puffed).
4.100-3000T/D leaching workshop turnkey project (Towline extractor, Rotocel extractor, loop type extractor, DTDC separated machine, the full negative pressure evaporation, paraffin wax recovery, leaching workshop degum, phospholipid concentrate).
5.30-1000T/D oil continuous grade two or one physical (chemical) refining production line.
6.20-600T/D Crude palm oil, rice bran oil, corn germ oil dewaxing turn-key project
7.10-200T/D Fatty acid esterification production cooking oil production line.
Flowchart:
Towline Extractor:
Rotocel Extractor:
Complete Line Assembling :
| Soybean meal extract process brief introduction: |
1. Solvent pumps: continuously spray solvent to the rotary-type extractor.
2. Roary extractor: Spray and soak the pre-pressed cake with solvent so that oil fats can be
diss-olved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil).
3. DTDC: usd to separate the solvent from the wet meal.
4. Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1st , then add saline water to it. The phospholipid in the miscella will react with the saline water, at last the reactant precipitate,
reaching the goal of purifying.
5. Miscella tank 2nd: the purified miscella will be pumped into it.
6. Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to condenser for recycling.
7. Condensers: used to cooling the solvent gas separated from the wet meal and miscella for recycling.
1.Ensure to timely provide complete sets of equipment and accessories.
2.Ensure that one-time installation debugging acceptance.
3.To provide high quality material with preferential price.
4.Priority to provide customer our new craftworks and products
5.Free training technological operator to ensure the trained staff can operation independently.
6.In the installation process,we will appoint a installation supervision staff on the spot.
7.we will offer an experienced project manager, organize a good installation team for the work of field installation debugging.
8.After the equipment field assembly and installation, we will be also responsible for the single equipment debugging, online debugging and Feeding trial operation, to ensure that equipments
can normal operate in full load conditions.
