Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

Product Description Of Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

1) Function: Oil extraction machine is an oil extractor through soaking or spraying pre-pressed cake by a certain organic solvent. The principle of this part is the different solubility of solvent.

2) Use range:Oil extraction machine fits for pre-press extraction of high-oil-content materials and direct once time extraction of low-oil-content materials.

3) Main parts: Oil extraction machine series includes rotary extractor, toaster, 1st evaporator, 2nd evaporator, stripping tower, condenser,etc.

Flow Chart Of Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

Main Parts Of Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

1) Solvent pumps: continuously spray solvent to the rotary-type extractor.

2) Rotary extractor: spray and soak the pre-pressed cake with solvent so that oil fats can be dissolved in solvent (form miscella). After processing,you can get wet meal and miscella (mixed oil).

3) DTDC: used to separate the solvent from the wet meal.

4) Miscella tank 1st: pump the miscella (oil with solvent) into the miscella 1st, then add 10% saline water to it. The phospholipids and impurities in the miscella will react with the saline water, at last the reactant precipitate, reaching the goal of purifying.

5) Miscella tank 2nd: the purified miscella will be pumped into it.

6) Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be discharged to condenser for recycling.

7) Condensers: used to cooling the solvent gas separated from the wet meal and miscella for recycling.

Main Process Of Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

After pressed or pre-pressed, we get the cake, the cake has about 7% or 12-13% oil residual. In order to make the oil in the cake is less than 1%, we need to solvent extraction. And Firstly, we need to by the scraper convenyor, send the cake to the solvent extractor, then leach them is about 90-120 minutes, keep the temperature 70-80 degree. There are mainly five prcess of oil solvent extraction: Solvent Extraction Process, Wet Meal Desolventizing Process, Miscella Evaporating Process, Solvent Condensation & Recovery Process, and  Paraffin Oil Recovery Process.

Product Overview About Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

Trading Process Of Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

 Our Services About Walnut/Sunflower/Palm Oil Extraction Plant/Equipment

1.Pre-sale services

System evaluation: Project basic situation.

Solution: The investment budget, feasibility, rationality.

Product selection: Factory inspection; Site measurement; Technical discusion; Supply professional drawing and lists.

Win-win Cooperation: Sign the contract; Establish mutual benefit, strategic cooperative partnership.

2.In-sale Services

Design evaluation: Detailed technical assessment & arrangement; Design of process and equipment layout.

Procurement: Strictly inspection, optimized selection.

Installation: Quality and quantity guaranteed; Completion of hand over.

Acceptance: Acceptance test; Accepted deliverables.

Technical training: On-site installation and products training; Operation skills training; Maintenance training; Centralized technical training.

3. After-sale Services

Technical service: Long time technical service.

Accessories supplying: Supplying spare parts with cost price.

Complaint handling: 12--24 hours response mechanism.

Client Review: Call-back; Regular return visit.

FAQ About Walnut/Sunflower/Palm Oil Extraction Plant/ Equipment

Q1 : Which kind of materials can be processed?

All kinds of oil seeds. For example, sunflower seeds, rice bran, corn germ, palm fruit, palm kernel,coconut,peanut, soybean, sesame, cottonseeds, rapeseed, etc.

Q2 : What's the capacity?

Generally, 10-3000 tons per day. We can also manufacture as per customers' requirements.

Q3 : How long is the warranty?

The main parts of the machine come with one year warranty and after the expiration our engineer is available overseas to do the maintenance work.

Q4 : Can the machine be installed locally?

We can do the turn-key projects or other services according to customers' requirements, according to this condition,our services can be manufacturing, purchasing, transporting, installation, training labors etc.

Q5 : How to operate the machine?

Our engineers will be available to guide and train your labors how to operate and run the machine.
