Home > Products > Biodiesel plant > used vegetable oil to biodiesel equipment, biodiesel plant
used vegetable oil to biodiesel equipment, biodiesel plant
- 300 Set / Sets per Month
- Qingdao Port or Lianyungang Port
- T/T L/C D/P D/A Credit Card PayPal
Product Details
| Brand Name: | HNYT | Model Number: | HNYT-07 | Place of Origin: | Henan, China |
| Application: | Vehicles | Grade: | B100 | Standard: | EN14241 |
Product Description
Cooking oil reuse machine making used vegetable oil for biodiesel
We are the biggest factory for producing biodiesel plant in China.So far our biodiesel plants have been exported to Dubai and Pakistan.Welcome to our factory for a visit.
1.began since year 1995
2.the listed company
3.goverment supported
In the full operating conditions, the expected consumption for producing of 1000 kg biodiesel meet standards using vegetable oil which contains more than 95% fatty acid:
Raw material / utility | Consumption |
95% crude animal or vegetable oil | 1058 kg-1100 kg |
vapor | 3350 kg |
cooling water(20/260C) | 32 m3 |
electric power | 63 kWh |
Instrument gas source | 10 Nm3 |
compressedair | 2 Nm3 |
Methanol(99.9%) | 115-140kg |
KOH(86%) | 8-12kg |
Catalyst | 8-12kg |
1. uses micro negative pressure, to maximum limit solve the dioxin emission, which is a worldwide difficult problem, thoroughly realize the garbage disposal harmless.
2. adopts dynamic seal, independently developed by our company, in order to solve seal leakage which is caused by cold and heat expansion in the process as well vibration in operation process, and then greatly improves the safety coefficient in production process.
3.The internal rotating screw plate, independently researched developed by our company, could reduce impurity intake in production process, avoid pipeline jam problem in the follow-up process section.
4.The the slagout system could run in sealed, avoid splashing and pollution during deslagging, give production workshop a good working environment.
5.Taking petrochemical standard in the noncondensable gas recovery, safety coefficient has been greatly upgraded, explosion accidents caused by backfire in recovery process could be avoided.
We can cooperate with customers in equipment, raw material, technology, sales and service, help our customers growing, and establish long-term, steady and win-win cooperation with customers.
1.One year guarantee for replacement main parts and free test and maintenance for life
2.On-site installation guide
Henan Pacific Energy Technology Co., Ltd. has passed ISO9001 quality management system, ISO14001 environmental management system, GB/T28001 Occupational Health and Safety Management System and CE and other international certification, who is China's first can produce biodiesel which meet EU standards. the quality of the product and the technology ,the technical level have been at the forefront of the same industry.
Now having 44 senior professional and technical staff are included: 19 doctors, 12 professors and associate professors, 13 senior engineers; having 40 sets large-scale comprehensive laboratory and international advanced experimental equipment; having 4 invention patents, more than 20 utility model patents. APETG covers an area of 335 acres, a total investment of 950 million RMB. Furthermore, we are the largest research and development of biodiesel production base in China.
