Jufeng Electrical Roller Miller Grain Grinding Machinery

FOB Price

US$ 2,999 - 19,999 / Set

1 Set(Min. Order)

Port Qingdao
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Henan, China
Brand Name	Diamond	Model Number	NF-2235
Production Capacity	300-500kg/h, 300-500kg/h	Voltage	380V, 380V
Power(W)	7.5kw	Weight	600kg
Dimension(LWH)	22008004000, 22008004000mm	Certification	ISO9001, ISO
Warranty	one year, one year	After-sales Service Provided	Engineers available to service machinery overseas

Product Description

Jufeng Electrical Roller Miller grain grinding machinery

Application of flour mill machine:

Roller mill is core equipment in flour mill plant. Roller mill generally have a pair of rollers which are speed-difference and opposing travel pair(s) of rollers, it could break and release wheat endosperm from wheat

cortex, and through continued grinding and rolling to achieve flour products. Materials mainly suffering

extrusion, grinding, and breaking effects, therefore get flour products. Every roller mill have two units driving

system to support independent driving, feeding, and grinding system working, so it could make many

different flow combination by use more than 2 unit roller mills to meet different technology aims.

Features of flour mill machine:

1. Manual clutch device;
2. Support the use of taper roller bearings, for easy removal;
3. Mainly used for supporting the construction of below 100 tons flour projects, it can also be used for crushing and grinding other feeders

Technical parameter of flour mill machine:

Type	Dimension (MM)				Power (KW)	Weight (KG)
Type	A	B	C	D	Power (KW)	Weight (KG)
JUFENG 5*2C	1350	850	750	510	4-18.5	2280
JUFENG 6*2C	1450	950	850	610	5.5-22	2430
JUFENG 8*2C	1650	1150	1050	810	5.5-22	2700

1. wheat storage (silos, or warehouse) ----------

2. cleaning system (sifter, destoner, seprater, magnet, scourer, etc) -----------

3. dampening (dampener, conditioning silos, etc) ----------

4. milling system (roller mill, plansifter, purifier, impact detacher, etc.) ----------

5. Flour pressure and blending system (if need) ----------

6. flour packing and stacking -----

7. PLC Controlling system

Equipment Name	Complete Set flour mill,flour milling machine, wheat flour mill
Output	30-500T/24Hrs
Main Cleaning Equipment	1).High-efficiency Virbration Sieve
	2).Destoner
	3).Corn Scourer
	4)Magnetic Separator
	5) compurter control dampener
Milling Equipment	1) electrical Roller Mill
	2).Plansifter
	3)Purifier
	4)High Pressure Blower
	5)Impact Detacher
Flour extraction rate(%)	Grade 1 flour:72%-75%,
	Grade 2 flour:73%-78%
	Design is with flour blending system. it is to satisfy customer's request on types of special purpose flour including bread flour, cake flour , biscuit flour, noodle flour etc.
Size of workshop	steel structure & multi-story cement building
Spare part	one year complete set spare parts for free
Advantage	1. With advanced technical process and flexible adjustment
	2.Adopt various configuration modes for different choices. There arestreamlined design, reasonable layout, and beautiful performance.
	3. Electrical parts are all famous international brand : SIEMENS, OMRON etc.
	4. Full automatic.

Complete line or single machine is welcome!!!!!!
