Home > Products > High Efficiency Plansifter > Small size and easy to install corn flour sieving machine
Small size and easy to install corn flour sieving machine
- 3 Unit / Units per Month
- SHANGHAI/ QINGDAO
- T/T
Product Details
Type: | flour milling machine | Use: | flour grading and cleaning | Certification: | ISO 9001:2001 |
Place of Origin: | Henan, China | Brand Name: | Diamond Brand | Model Number: | FSFG type |
Condition: | New | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
High Effective Square Plansifter For The Powder
Specifications
1. Patented Aluminum Alloy Sieve Frame
2..Excellent Sanitation
3. High Sifting Capacity
4. Flexible and Reliable Application
Square Plansifter
Introduction:
FSFG series square plan sifter is employed in grain milling ahead of bagging for the sifting and re-bolting
(final sifting) of break stocks, flours, bran and intermediate mill stocks as well as for the grading of floury materials, semolina.
It is suited for grain processing plants of all kinds like food processing, Brewing industry, animal feed processing plants etc.
Technical parameter:
Type | Grids per Case (GRID) | Screen Area (M2) | Rotating Diameter per Case (M) | Principal Axis Speed (R/MIN) | Minimum Installment Height (MM) | Power (KW) | Weight (KG) | Size (MM) |
FSFG4X16 | 16-18 | 18-25 | 64 | 245 | 3180 | 2.2 | 2200 | 2410*1870*1880 |
FSFG4X22 | 22-24 | 24.7-33.4 | 64 | 245 | 3540 | 3 | 2500 | 2410*1780*2240 |
FSFG4X24 | 24-27 | 40.5-56.3 | 64 | 245 | 3730 | 4 | 3530 | 2410*2550*243 |
Working principle:
1. Adopts high quality steel plates;
2. Advanced bending machine and argon arc welder are employed for edge-folding and welding;
3. Galvanized bolts ensures sturdy structure;
4. The sieves are well designed, resulting in high accuracy and long service life;
5. Great sanitation thanks to the enclosed structure;
6. Equipped with GRP boom, durable and wear-resistant.
Contact Us
- Henan Zhongyuan Roller Co., Ltd.
- Contact nameJoshua wang
- Phone86-395-6161165
- AddressLuoheshi Yan city meng miao town zhongyuan road no. 45 Luohe,Henan
