Jinxin sunflower oil extraction machinery
Sunflower oil is the most widely used oil due to its high linoleic content which is considered nutritionally positive. The kernel accounts for 70% of the seed and the oil content is about 40%-45% in the seeds.
The whole sunflower oil making line contains three workshops:
sunflower oil extraction machinery flowchart:
Oil seeds → cleaning → softening → prepressing → drying → to extraction workshop
sunflower oil production equipment
a. Cleaning device:remove the raw material peanut in various impurities, such as: iron,
stones, clump, such as the plant leaf, clean up till impurity content does not exceed 0.2%.
b.Crushing machine: peanut is crushed into 6-8 pieces. In order to meet the requirements
of crushing, the peanut is suitable for crushing with the moisture of 7% to 12%.
c. Softening process:the purpose of softening is to adjust the moisture and temperature
of oil, and make it soft.
d.Flaking process: rolling raw material into flakes, and the purpose is to increae surface
area, destroy the peanut cell tissue, shorten the way of oil out from cake.
e:Cooking process: use steam cooking, inject direct steam and cook the flakes to meet the
requirement of oil press.
f.Pre-press: press the flakes to leave about 16%-18% in the cake. The cake will go to extraction
process.
sunflower oil extraction machinery process:
1. Solvent pumps: continuously spray solvent to the rotary-type extractor
2. Roary extractor: Spray and soak the pre-pressed cake with solvent so that oil fats can be
dissolved in solvent(form miscella). After processing, you can get wet meal and miscella (mixed oil).
3. DTDC: usd to separate the solvent from the wet meal.
4. Miscella tank 1st: pump the miscella (oil with solvent) in to the miscella 1st , then add saline
water to it. The phospholipid in the miscella will react with the saline water, at last the reactant
precipitate, reaching the goal of purifying.
5. Miscella tank 2nd: the purified miscella will be pumped into it.
6. Miscella stripping: it will remove the remaining solvent in miscella. And the solvent will be
discharged to condenser for recycling.
7. Condensers: to cooling the solvent gas separated from the wet meal and miscella for recycling.
sunflower oil extraction machinery advantage:
1.Our products have the high quality and high performance.we use the stainless steel instead
of the carbon steel.
2.we buy directly from the manufacturer for guaranteeing the quality.
3.our welding worker should get the certificates.and our electric machines all imported from
Germany.
And more other advantages we will talk in our specific condition.
sunflower oil extraction machinery consumption in operation:
Residual oil in meal |
≤1% (SUNFLOWER SEED) |
Solvent consumption |
≤3Kg/T(6#solvent oil) |
Crude oil moisture and volatile matter |
≤ 0.30% |
Power consumption |
≤ 15KWh/T |
Steam consumption |
≤280Kg/T (0.8MPa) |
Finished meal moisture |
≤ 10-13% (adjustable) |
Residual solvent in finished meal |
≤ 300PPM (qualified detonated experiment |
