30Ton Low price automatic peanuts oil processing machine
peanuts oil processing machine introduction :
peanuts oil processing machine including the extraction of pre-pressed cake, miscella evaporation at negative pressure, stripping, wet meal desolventizing, solvent vapor condensation,
vent gas recovery and so on.
1.Extracting of peanuts oil processing machine
The pre-pressed cake, firstly enter into the sealed scraper blade to avoid the solvent gas escaping. Sunflower seeds enter into the extractor counter-currenting with the solvent, the grease is extracted. Miscella condensity increase from 2% to more than 25%. Miscella discharged from extractor,
then into miscella filter, and the leached meal finally drop-in DTDC out from wet meal drag conveyor.
2.Evaporation of peanuts oil processing machine
Using the secondary steam desolventized from DTC desolventizer and produced by steam-jet pump to heat and evaporate micella in the first long-tube evaporator. Export temperature reaches to 58-62℃ and condensity reaches to more than 65%. Then, micella enters into the second long-tube evaporator in which the temperature is heated to 90-95℃ by indirect steam and the condensity reaches to more than 95%. Then miscella enters into stripper in which residual solvent in oil will be removed,
the export temperature reaches to about 105℃ and the general volatile of the extracted crude oil is less than 0.30%.
3.Desolventizing of peanuts oil processing machine
Wet meal in seal scraper blade drop-in DTDC evapo-separated machine through material seal screw for desolventizing, drying and cooling. The machine has eight layers and its flow controlling gate is flexible
and reliable.Desolventizing baiting layer uses seal screw.
4.Condensation recovery of peanuts oil processing machine
Extractor is equiped with a seperate condenser, 1st and 2nd evaporation share one condenser. Low and high temperature of solvent gas both from 1st
and 2nd evaporation enter into the condenser after its neutralization, which greatly reduces the load of condenser and improves the efficiency of condensing.
Stripping and analyzing share one condenser, the non-condensable gases enter into the vent gas recovery system through the final condenser.
In the recycling system, the cold paraffin will absorb the solvent gas and the final nonsolvent gas will be discharged through fire resistance valve.
Paraffin absorbed the solvent gas can be also called rich oil, after heating by oil-oil heat exchanger and steam, the rich oil will enter into desorber for desorption, and into condenser after changing solvent into gas,
the final cooled paraffin can be recycled.
Packing : Packed by the protect film inner, water-repellent plastic outside. The wood packing is necessary if send by less than a container. it will fixed by steel rope in the container.
Make sure it is in good condition when arrived destination.
Shipping : 30 days after receiving your L/C or deposit
Dear Sir, when you need edible oil machine, cooking oil making machine,
Vegetable oil processing machine, please send me email about your requirement.
Thank you for your time!
If you need find reliable and professional Chinese supplier to provide
high quality Edible oil factory, contact us please.
