Home > Products > Coconut Oil Making Line > High Oil Extraction Rate Technology Coconut Oil Equipments
High Oil Extraction Rate Technology Coconut Oil Equipments
- Any port in China
- T/T
You May Like
Product Details
| Condition | New | Usage | Other, coconut oil equipments | |
| Type | Other, coconut oil equipments | Automatic Grade | Automatic | |
| Production Capacity | 10T-3000T/D | Place of Origin | Henan, China | |
| Brand Name | JinXin | Model Number | For soybean oil production machine usage | |
| Voltage | 220V/380V | Power(W) | Accoding to soybean oil production machine capacity | |
| Dimension(L*W*H) | Accoding soybean oil production machine capacity | Weight | Accoding to soybean oil production machine capacity | |
| Certification | ISO9001:2008 | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
High oil extraction rate technology coconut oil equipments
WHY Choose us
1,Over 25 years experience in oil pressing equipment field, ranking first in Henan,China.
2, Cooperate with Henan Machine Design Research Institute and Henan University of Technology in the oil equipment, protein extraction, phospholipid extraction,etc. R&D and application of new technology.
3,The only one who owns the CE Certificate, Quality Systerm Certificate, France BV Certificate, which guarantee the quality of the equipment.
4,DTDC Desolventizer with most advanced technology in solvent extraction section and Automatic Contorl System.
Main Technology
1,Pretreatment and Pre-pressing technology.
2,Solvent Extraction Technology.
3,Edible oil Refining Technology.
4,Dewaxing and Degreasing Technology.
5,Soybean protein concentrated and protein isolates Technology.
6,Peanut oil cold pressing and superfine fragrant peanut oil Technology.
7,Palm fruit pressing Technology.
8,Palm oil fractionation Technology.
Main Business Field
1.10-500T/H oil material first cleaning,drying and storage section turn-key project.
2.100-3000 T/D oil pretreatment, shelling and pre-press workshop turnkey project (soybean hot peeling, bean skin crushing; the soybean extrusion, high oil contained pre-press cake extrusion, and high oil contained embryos puffed; of direct puffed). Rice bran production line turn-key project.
3.Leaching workshop turnkey project (Towline extractor, Rotocel extractor, loop type extractor, DTDC separated machine, the full negative pressure evaporation, paraffin wax recovery, leaching workshop degum, phospholipid concentrate).
4.30-1000T/D oil continuous grade two or one physical (chemical) refining production line.
5.20-600T/D sunflower oil, rice bran oil, corn germ oil dewaxing turn-key project
6.10-200T/D Fatty acid esterification production cooking oil production line.
Available oil crops
The techmology of my company for pretreatment and pre-pressing which mainly include the cleaning , decrustation extrusion,flaking,cooking and pre-pressing and so on .Considering the different characteristic of oil seeds and the customer requirements,we can provide you the special design,in order to adjust the oilseed to the optimun state ,which will improve the oil yield and the cake quality.
Pretreatment process feature:
1) Different combinations of process can process various oil plants in one workshop.
2) Use special intensified pretreatment technology for aroma peanut oil to make it more aroma.
3) Adopt advanced and reliable shelling technology to meet higher requirements for protein content in meal.
4) Extrusion treatment is used for raw materials with hard extraction, large-sized powder, and large capacity, which can reduce residual oil and solvent consumption, and increase the capacity by 50-80%.
5) The new technology of shelling and low-temperature treatment can ensure high protein and least denaturation.
Pretreatment flow chart for soybean oil
Cleaning →Crushing→ Husking→Softenning→Flaking→Puffing→Counter Flow Drying→To Extraction workshop
Flaking machine
Solvent Extraction Flow chart for soybean oil
Rotocel Extractor
1. Adopt stainless steel fixed grid plate and increase the horizontal grid plates, which can prevent the strong miscella from flowing back to the blanking case, so as to ensure good extraction effect;
2. The rotocel extractor is driven by rack, with unique rotor of balanced design, low rotating speed, low power, smooth operation, no noise and quite low maintenance cost;
3. The feeding system can adjust the rotating speed of airlock and main engine according to the feeding quantity and maintain a certain material level, which is beneficial to the micro negative pressure inside the extractor and reduce the solvent leakage.
4. The advanced miscella circulation process is designed to reduce the fresh solvent inputs, reduce the residual oil in meal, improve the miscella concentration and save energy by reducing the evaporation capacity.
5. The high material layer of the extractor helps to form immersion extraction, reduce the meal quality in miscella, improve the quality of crude oil and reduce the evaporation system scaling.
6. Specially suitable for the extraction of various pre-pressed meals.
Twoline Extractor
1. The material is divided into several independent units on the material bed, which can effectively prevent miscella at all levels from fleeing hither and thither on the material layer and ensure the concentration gradient between several sprays.
2.Immersion area appears in each lattice, which can help achieve better immersion effect.
3.The chain box is supported by track and can prolong the service life of screen deck by not touching it.
4.The towline extractor is driven by world leading double-shaft hydraulic motor, with balance force, reliable operation and less maintenance cost.
5. Specialty suitable for the extraction of high oil and high power materials, and better immersion effect can be expected for ordinary oil plants.
Desolventizer(DTDC)
Solvent condensation & recovery
Main Parameters
Residual oil in meal | ≤1% (Peanut) |
Solvent consumption | ≤3Kg/T(6#solvent oil) |
Crude oil moisture and volatile matter | ≤ 0.30% |
Power consumption | ≤ 15KWh/T |
Steam consumption | ≤280Kg/T (0.8MPa) |
Finished meal moisture | ≤ 10-13% (adjustable) |
Residual solvent in finished meal | ≤ 300PPM (qualified detonated experiment |
Refining flow chart for soybean oil
Main Paramaters
Soft water consumption | ≤ 160Kg/H |
Steam consumption | ≤ 300Kg/T oil |
Bleaching earth | 1-3Kg/T oil |
Power consumption | ≤ 22KWH/T oil |
Fuel consumption | 10-20Kg/T oil |
Oil content in waste white clay | ≤ 23% |
Phosphoric consumption | 0.5-1Kg/T oil |
1.Deacidification
Sodium hydroxide antagonize free fatty acids,and subside phospholipids,to remove the insoluble impurities,then after the separation of soapstock, neutral oil was washed in soft water,last drying in vacuum.
2.Bleaching
Used to remove off pigments, bleaching oils and grease dehydrate
3.Deodorization
Using high temperature and high vacuum steam stripping method deodorization temperature commonly 180, vacuum degree 9.3 104 Pa can achieve ideal results
4.Dewaxing
Dewaxing can ensure the colour of the oil to be clear bright at room temperature and frozen temperature. to reduce the oil in the wax content to 10 parts per million to get crystal clear oil.
We specialize in manufacturing oil making machine and equipment. Established in 1989. With more than 25 years experiences in this field, We have exported our equipments to many countries like Egypt, Chile, Argentina, Ethiopia, Zambia, Nigeria, Russia and Turkey etc.
Pre-sale
System evaluation: 1)Project basic situation
Solution: 1)The investment budget. 2)Feasibility, rationality
Product selection: 1)Factory inspection. 2)Site measurement. 3)Technical discussion. 4)Supply professional drawing and lists.
Win--win coopration: 1)Sign the contract. 2) Establish mutual benefit, strategic cooprative partnership.
In-sale
Design evaluation:1) Detailed technical assessment, arrangement. 2)Design of process and equipment layout.
Procurement: Strictly inspection, optimized selection.
Installation: 1)Quality and quantity guaranteed. 2)Completion of hand over.
Acceptance:1)Acceptance test. 2)Accepted deliverable
Technical training: 1)On-site installation and products training. 2) Operation skills training. 3) Maintenance training. 4) Centralized technical training
After-sale
Technical service: Long time technical service
Accessories supplying: Supplying spare parts with cost price.
Feel free contact me to get more information
