China Manufacturied Factory of Coconut Oil Extract Plant

China manufacturied factory of coconut oil extract plant

Contact Me

Name: Helen

Skype: jinxin021

Phone: 008615838271596

Raw material

Coconut oil press machine:

Coconut oil press machine operation priciple:

The first step: Open the cap of the oil tank,and fill in the hydraulic oil into it.

The secind step: Open the red switch of Power Distribution Cabinet to preheat the machine.

The third step: One hand hold the handle,then the other one pull the cap of the machine,and

   pour the oil material into the charging barrel. (if the oil material is not so much,we can put them into the special bag,cos the heavy pressure can make the oil material flow through the oil-way,and stop it up).

The fourth step: Put the iron mat onto the oil material and close the cap,and tighten the nut on it .

The fifth step: Turn the high-pressure reflux valve and the machine start to work.At the same time,the oil tank will go up to press the oil material and the oil follow from the oil way by the high pressure.

The sixth step: There will be an oil-out beside the lacquer tray,below it,we can put down the oil can for oil collection.

The seven step: The machine will stop work for a while, when the pressure is under some degree,and after several minutes,the second pressing will begin automatically,ans when the pressure goes to the adjusting degree,the presser will be stoped for the first ending.

The eight step: Stop the the high-pressure reflux valve and let the oil tank go down,loosen the nut and open the cap,then the meal will go up as the oil tank rising up,take the meal out of the machine,and break it manually. Tips:The second pressing and third pressing are the same as the first one.And there is a temperature-controlled setting on the distribution box,when you open it,the machine can be heated by the infrared ray,and you can choose the ways of pressing,hot or cold by yourselves.

Coconut oil mill machine flowchart:

1.Press section flowchart:

Metering →Cleaning →Magnetic separation→Destoner→Crushing  →Softening  →Flaking  →Cooking →Pre-pressing  →go to extraction section               ↓

                Second oil press

Coconut oil mill machine introduction:

a. Cleaning device:remove the raw material peanut in various impurities, such as: iron,

stones, clump, such as the plant leaf, clean up till impurity content does not exceed 0.2%.

b.Crushing machine: peanut is crushed into 6-8 pieces. In order to meet the requirements

of crushing, the peanut is suitable for crushing with the moisture of  7% to 12%.

c. Softening process:the purpose of softening is to adjust the moisture and temperature

of oil, and make it soft.

d.Flaking process: rolling raw material into flakes, and the purpose is to increae surface

area, destroy the peanut cell tissue, shorten the way of oil out from cake.

e:Cooking process: use steam cooking, inject direct steam and cook the flakes to meet the

requirement of oil press.

f.Pre-press: press the flakes to leave about 16%-18% in the cake. The cake will go to extraction

process.

g.Second oil oress: Press the cake till the oil residue is about 5%.

Coconut oil mill machine consumption in operation:
