High Quality Steel Castor Seeds Oil Press Equipment

High quality steel castor seeds oil press equipment

WHY Choose us

1,Over 30 years experience in oil pressing equipment field, ranking first in Henan,China.

2, Cooperate with Henan Machine Design  Research Institute and Henan University of Technology in the oil equipment, protein extraction, phospholipid extraction,etc. R&D and application of new technology.

3, Approval by CE Certificate, Quality Systerm Certificate, France BV Certificate, which guarantee the quality of the equipment.

4,DTDC Desolventizer with most advanced technology in solvent extraction section and Automatic Contorl System.

Main Technology

1,Pretreatment and Pre-pressing technology.

2,Solvent Extraction Technology.

3,Edible oil Refining Technology.

4,Dewaxing and Degreasing Technology.

5,Soybean protein concentrated and protein isolates Technology.

6,Peanut oil cold pressing and superfine fragrant peanut oil Technology.

7,Palm fruit pressing Technology.

8,Palm oil fractionation Technology.

Main Business Field

1.10-500T/H oil material first cleaning,drying and storage section turn-key project.
2.100-3000 T/D oil pretreatment, shelling and pre-press workshop turnkey project (soybean hot peeling, bean skin crushing; the soybean extrusion, high oil contained pre-press cake extrusion, and high oil contained embryos puffed; of direct puffed). Rice bran production line turn-key project.
3.Leaching workshop turnkey project (Towline extractor, Rotocel extractor, loop type extractor, DTDC separated machine, the full negative pressure evaporation, paraffin wax recovery, leaching workshop degum, phospholipid concentrate).
4.30-1000T/D oil continuous grade two or one physical (chemical) refining production line.
5.20-600T/D sunflower oil, rice bran oil, corn germ oil dewaxing turn-key project
6.10-200T/D Fatty acid esterification production cooking oil production line.

7.30-300T/D Palm oil pressing line.

Available oil crops

Screw oil press machine

Operating principle:

1.When oil press is on work, material enters the extruding chamber from the hopper and then moves forwards by the rotating pressing screw and is pressed.

2.Under hightemperature condition in the chamber, there is quite strong friction among press screw, chamber and the oil materials.

3.On the other hand, root diameter of the pressing screw carries larger from one end to the other.

4.Hence when rotating, the thread not only pushes particles moving forwards but also turns them outwards as well.

5.Meanwhile, particles adjacent the screw will rotate along with screw’s rotating, causing every particle inside the chamber to possess different speed.

6.Therefore, relative movement among particles creates neat which is necessary during manufacturing because of helping protein change property, damage colloid, increase plasticity, decrease oil’s elasticity, resulting in high oil.

Construction features:

6YL series spiral oil press is mainly composed of 7 major parts of screw axis, press cage, feed mechanism, cake yielding mechanism. transmission system, electric control part and vacuum filter part. All the parts are assembled on the frame and screwed as a whole.

Characters:

Simple design , easy to operate , wide suitability , continuous operation, high productivity and high oil product ratio.

 Advantage

Energy saving-----equal 40% lower electric power production, with the average small 6 KWH saving calculation, electricity production can save 30 yuan.

Saving of labor-----the same production can save Labour 60%, 1 to 2 people to organize production.

Widely used------ multi-usage, squeeze peanuts, sesame, rapeseed, soybean, canopy, flax ,more than 20 oil crops. Level 3 press, a squeeze net.

Oily pure----- vacuum filter residue and ensure the pure oil, conform to the health and quarantine standards.

Covers an small area----- oil mill only needs 10 to 20 square meters can satisfy the production need.

Approvals
