Specifications
Fixed-capacity dry white wine fermentation and storage tanks designed for dry white wine.
Prouduct introduction
Fixed-capacity dry white wine fermentation and storage tanks designed for dry white wine.These come from Sylvania design aesthetic side of the tank with elliptical manhole,a two-inch outfall,filling a two-inch hole,a sampling valve,and many more accessories (see the following attached parts) to ensure high-quality wines and ease of use.Gradient of 10% (optional 15% or 35%) the end of the ramp structure makes it easier fermentation and emptied.These can also be equipped with temperature control system (Jacket,double bottom,temperature controller,etc.)
Equipment
Drain port DKE 2' TRI CLOVER (tanks 500gal,750gal and 1000gal) or DKC2' TRI CLOVER (tanks 1500gal and 2000gal)
Racking port 2' TRI CLOVER
Oval manway 310 x 440 mm,the frame seamlessly formed out of the tank wall (tanks 500gal) or oval manway
Top manwany 420mm
Connection for thermometer 1/2' NPT
Connection for probe 1/2' NPT
Cooling jacket Vt h750mm 6bar
Lifting rings
Ladder hoider,width 410mm
Accessories
Sample valve 3/4' TRI CLOVER
Clamp 3/4' TRI CLOVER
Gasket 3/4' TRI CLOVER
Preesure compensating valve DIN 50
Material:ALSI 316L-tank lid,AISI304-other parts
