Home > Products > Pharmaceutical machinery > FXG Series fermentation tank
FXG Series fermentation tank
- 20 Set / Sets per Month
- Shanihai
You May Like
Product Details
| Condition | New | Place of Origin | Jiangsu, China | |
| Brand Name | JFENG | Model Number | FXG | |
| Type | Processing Line | Voltage | 220V/380V | |
| Power(W) | according to type | Weight | according to type | |
| Dimension(L*W*H) | according to type | Certification | ISO9001 | |
| Warranty | 1 Year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
FXG Series fermentation tank
Usage:
It’s a kind of equipment for mechanical mixing and zymolysis. It’s inner circulation type, dispersing foam by blades and breaking them into pieces. Asepsis respiration system or asepsis compression ferment system are specially design and installation parts. Tank body covered with jacket, material medium circulation heating or cooling can be done via jacket. Made by high quality stainless steel plate which has good durable performance according to GMP standard.
Technology parameter:
Parameter/Type | FXG0.05 | FXG0.1 | FXG0.2 | FXG0.5 | FXG1.0 | FXG2.0 | FXG5.0 | FXG10.0 | FXG20.0 | FXG50.0 | FXG60.0 |
Diameter(mm) | 50 | 100 | 200 | 500 | 1000 | 2000 | 5000 | 10000 | 20000 | 50000 | 60000 |
Height(mm) | 400 | 500 | 500 | 700 | 900 | 1100 | 1400 | 1800 | 2300 | 3100 | 3200 |
Pressure inside tank(Mpa) | 990 | 1135 | 2330 | 2600 | 2900 | 3800 | 4545 | 5250 | 6550 | 8550 | 10730 |
Pressure inside jacket(Mpa) |
|
|
|
|
| 0.3 |
|
|
|
|
|
Qty.of blade | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 4 | 4 | 4 |
Mixing speed(rpm) | 360 | 360 | 360 | 220 | 180 | 136 | 136 | 125 | 110 | 110 | 110 |
Mixing power(kw) | 0.55 | 0.55 | 0.75 | 1.1 | 3 | 3 | 5.5 | 11.5 | 23 | 55 | 55 |
Heating type | Jacket Heat-exchange tube | ||||||||||
Jufeng enterprise is a professional diversfied machinery manufacturer integrating design, development,manufacturing,engineering installation,after-sales service,etc. The company took the lead among the industry in obtaining the National D-class "special equipment manufacturing license" and ISO9001:2000 international quality system certification.
About Delivery time
Q-----What’s the delivery term for making business with us?
A----- FOB, CFR & CIF optional; It’s mainly depend on client’s requirement;
About Lead Time
Q------What’s the lead time after placing order?
A------Usually it takes about 25~30 days after we received your deposit.
However, it would depend on our production line schedule(the timing clients place order)and the complication of the item.
About Payment Term
Q------What’s the Payment Term?
A------ By T/T in Advance, or Irrevocable L/C at Sight.
Our equipments can be customized, leave an inquiry to know more details about price, packing, shipping and price.
