This equipment is suitable for concentration liquid material and recycling the alcohol and other organic solvent in pharmaceutical, foodstuff and chemical industry etc.
Summarize:
1.This equipment is consist of heater,evaporator,condenser,cooler,etc.In view of recycling alcohol and other organic solvents,the evaporation area and the condensate area are extended and the top of evaporator room is equipped with the foam killer to make organic solvent consumption lower below 3% (JFAR series).
2.The whole process is in a vacuum condition in order to avoid polluting. It is with fast evaporation speed and the concentration proportion can get above to 1.2.
3.The top of heater is with opening device so it is easy to clean. The equipment is also with automacit drainage system in order to lighten the labor intensity .
Main technical parameter:
model |
JFAR-2000 |
JFAR -1500 |
JFAR -1000 |
JFAR -500 |
evaporate capacity(kg/h) |
2000 |
1500 |
1000 |
500 |
vacuum rate(Mpa) |
0.02~0.09 |
|||
steam pressure(Mpa) |
<0.1 |
<0.1 |
<0.1 |
<0.1 |
condension(m2) |
28*2 |
20*2 |
14*2 |
7*2 |
heating area(m2) |
24 |
18 |
12 |
6 |
demension(m) |
4.7*1.2*4.6 |
4.2*1.1*4.5 |
4.2*1.1*4 |
3.3*0.9*3.4 |
