Seed Tank JFST-100

Applicable range

1. Commonly applicable for incubating work fermentation agent for acidophilus milk.

2.Ideal in fields such as foods,dairy products,fruit juice beverages,pharmacy,chemical industry and biological engineering etc.

Structure characteristics

1.Adopt structure of internal tank and external package,with heat preservation materials inside

2.Materials are all sanitary stainless steel

3.Humanized structure design and easy to operate

4.Transition area of interior wall on tank adopts arc for transition to ensure no dead corner of sanitation

5.Top head sealing adopts rotary opening type.For tank with 400L volume,adopts hermetic structure

Configuration of tank

1.Sterile respirator

2.Thermometer (According to customers' inquirements)

3.CIP cleaning ball

4.Inlet of seed

5.Adjustable triangular bracket

6.Blender

7.Jacket (Miller board or hollow jacket are available according to customer requirements)

8.View lamp (According to customers' inquirements)

9.Sampling valve

Note

It can be made according to special requirements fo customers.Total hight (H) is  in accordance with outlet height of 800mm. If outlet height is changed,the total height (H) shall also be adjusted.
