Tire strip cutting machine has function of make full use of tires
Rubber cutter hand tool
Application of rubber cutter hand tool
Rubber cutter hand tool is used to separate the tire side from the whole tire. Now the steel wire from tire sides of vacuum tires is thick and hard to curve, so before feeding the waste tires into reactor, it is better to cut the tire sides down. Besides, this part of tire has good value, rubber cutter hand tool helps collecting these thick steel wires.
Technical parameters of rubber cutter hand tool
Model | Production | Power | Size of Tires | Dimension |
QKF850 | 2.01ton/h | 2.2KW | φ82~1200mm | 1200*850*1405mm |
Working principle of rubber cutter hand tool
Place the waste tire on the round terrace; rotate the hand wheel so that thinner side of the tire can be locked by the four claws frame. Then turn on the power, the terrace will begin to rotate with the tire, and then make the cuttingknife cut into the tire according to the need until cut down the whole sidewall.
Tire strip cutting machine
Application of tire strip cutting machine
Tire strip cutting machine is used with circle cutting machine and could cut the tires without tire sides into strips.
Technical parameters of tire strip cutting machine
Power | Size of Tire | Dimension | ||
QT380 | 1ton/h | 4KW | ≤φ1200mm | 1330×700×1580mm |
Block electric rubber cutter
Application of block electric rubber cutter
Waste tire block cutting machine is utilized to process the rubber stripes into rubber blocks with a certain size, which is good for latter production and improving work efficiency. It is generally used along with bar cutter, and it is essential equipment for waste tires processing.
Technical parameters of block electric rubber cutter
Model | Power | Weight | Size of Tire | Dimension |
QK200 | 7.5KW | 450KG | ≤φ1200mm | 800*810*1070mm |
Hydraulic cutting machine
Application of hydraulic cutting machine
Hydraulic cutting machine is used to process the waste tires and cut the tires into pieces and meets the demands of clients who have big size tires.
Technical Parameters of hydraulic cutting machine
Model | Power | Weigh | Size of Tire | Dimension |
QDY 700 | 5.5KW | 1300 | φ800~1200mm | 1720*750*1880mm |
Packing & Shipping of tire strip cutting machine
All the goods exported are packed in wooden case or carton with export standard except naked package when necessary. We have our own professional shipping company which could deliver the goods to every corner in the world with safety and speed, and also can supply the services of solving the problemsoccurred
Our service of tire strip cutting machine
1. Pre-sale services of tire strip cutting machine
Act as a good adviser and assistant of clients; enable them to get rich and generous returns on their investment
(1) Select equipment model;
(2) Design and manufacture products according to clients’ special requirement;
(3) Train technical personnel for clients.
2. Services during the sale:
Respect clients; devote ourselves to improving the total value of clients.
(1) Pre-check and accept products ahead of delivery;
(2) Help clients to draft solving plans.
3. After-sale services of tire strip cutting machine
Provide considerate services to minimize clients’ worries.
(1) Assist clients to prepare for the first construction scheme;
(2) Install and debug the equipment;
(3) Train the first-line operators on site;
(4) Examine the equipment regularly;
(5)Take initiative to eliminate the troubles rapidly at site;
(6) Distribute the guarantee fittings door-to-door;
(7) Provide perfect service;
Company information:
Henan Doing Mechanical Equipment Co, Ltd. is a professional manufacturer of tire strip cutting machine; we have been in this field for 10 years. With rich experiences, our engineer team helps customers design different tire strip cutting machine with different capacities.
