AE300L-P Lab High Shear Emulsifier
Please ask me for the manual if you need it!
♦Introductions♦
AE300L-P laboratory shearing emulsification machine adopts compact structural
series high speed mini dynamo drive, which is used to the following things in lab or
middle stage test workshop, such as, low to middle or high viscosity liquid stirring
mixture, pulverizing particle material is sheared or emulsified in liquid medium.
The machine consists of driving dynamo whose body is high-density aluminium die-cast alloy, shearing emulsifying working head made of excellent stainless steel,
speed controller.
1.Lab High Shear Emulsifier has Various of agitators are designed for different
processing capacity and difference experiment requirement And easy operate and
easy clean easy maintainance .
2.Variable Rating Speed Control provide with a high effect.
Technical parameter
♦ Shearing emulsification theory ♦
High-speed dynamo drives the shearing emulsification working head, cooperating
precise rotor and stator of working head. High-speed rotation of rotor will form some comprehensive kinetic energy, such as,
high-frequency and violent tangent to periphery speed and rotation velocity.
The laboratory material will be inhaled to rotor area from the bottom of laboratory
container and will be thrown out from the stator hole by centrifugal force. Stator and
rotor will form combined effect in a reasonable slit, such as, violent and reciprocating hydraulic shear, friction, centrifugal extrusion, and flow collision. The laboratory
material repeats the previous working process and bears shear, avulsion, impact and mixture which reach ten thousands of times per minute. The shearing emulsification effect can be reached. The effect will be 1000 times higher than ordinary stirring.
The laboratory shearing emulsification machine can be used in the following fields,
such as, organization dispersion of Biotechnology field, sample preparation of
medicine field, enzyme treatment of food industry, pharmacy industry, cosmetic
industry, paint industry and petrochemical engineering industry, etc as well as some
liquid material.
The experimental medium can be refined by extrusion, impact and
mixture, and they can be mixed more averagely, so as to prevent and lower the layers with feed liquid, Such as, homogeneous and emulsifying process of homogenate,
histocyte of dairy products, beverage, cosmetics, drug .Working head configurations of different specifications are designed to satisfy different experimental demands,
covering more extended applications-smash, emulsify, homogeneity, polymerize,
suspension, dissolve, and stir.
♦ Packing list ♦
No. | Name | Unit | Quantity |
1 | Emulsification host | piece | 1 |
2 | Base | a | 1 |
3 | Stand column | stick | 2 |
4 | Backbone | stick | 1 |
5 | Supporting fixed frame | piece | 1 |
6 | Speed controller | piece | 1 |
No. | Name | Unit | Quantity |
7 | Power wire | stick | 1 |
8 | Stator 5mm² | piece | 1 |
9 | Stator 50mm² | piece | 1 |
10 | M5 wrench | piece | 1 |
11 | Electric brush(accessory) | pair | 1 |
12 | Product qualification certificate | a | 1 |
13 | Operation | a | 1 |
♦ Technical parameters ♦
Rated supply voltage: AC 220V | Material of working head: stainless steel 304L |
Input power: 510W | Diameter of working head: 70 mm |
Output power: 300w | Maximum torque: 93 Ncm |
Nominal torque: 0.96 Nm | Stator configuration of Working head: 5/20/50 mm2 |
Working form: 100% | Unity machine dimensions: 360x260x760mm |
Rotational speed control: variable | Controlling box dimensions: 240x120x150mm |
Spindle speed: 200-11000 rpm | Temperature: ≤40°C |
Operational capacity: 40000 ml | Humidity: ≤90% |
