Nut & Seed Oil Expeller Oil press
Operation requirement
Components
This machine consists of frame, press part, driver part and heating part etc. In view of environmental protection and recycling, material feeding/collecting equipment can be replaced with drink bottle, which is prepared by buyer.
Assembly
Before operation please fix the frame and make sure crank can be turned freely. Lubricate washer with edible oil and insert on screw shaft from the small end.
Insert screw shaft in press cage. Screw on press cage cap and screw on terminal adjustment bolt. Attach crank arm to screw shaft and tighten the bolt. Fill 80% fuel to the lamp bottle (kerosene or alcohol). Pass a 15cm wick through the washer. Leave 0.5cm of wick outside and put the longer end in the fuel bottle. Place washer at the bottle mouth. Place the lamp under press cage. Secure the lamp with rubber band.
Heating
To guarantee the oil output, the press cage should be heated for about 10 minutes. when the press cage temperature reaches 50-70℃, material can be put into inlet for pressing. The lamp remains heating during pressing as well.
Operation
Step1: Make sure no impurities in the material before pressing.
Step2, At the beginning of pressing, oil flowing from the terminal adjustment bolt is normal.
Step3, Loose the terminal adjustment bolt if the discharged cake is too dry and crank turning
resistance is too big
Step4, Tighten the terminal adjustment bolt if the discharged cake contains too much oil residual.
Cleaning
Clean the oil press immediately after operation. Otherwise residual in the machine will get hard and affect next operation.
Safety and warnings
Material friction and lamp heating cause very hot press cage, press cage cap and terminal adjustment bolt. Keep hands clear of the hot parts. And if you indeed need operate the hot parts please take reasonable protection steps.
Notes
With technology renewal our product is improved continuously. We are not liable for informing buyer about product change in future.
Accessories
Crank
Fuel Bottle
Frame
Screw Shaft
Press Press Cage Cap
Terminal Adjustment Bolt
Will process oils from:
Almond Babassu Kernel
Beechnut Cocoa Bean Coconut Hazelnut Hempseed Jatropha Linseed
Niger Seed Oil Palm Kernel Peanut Pumpkin Seed Rapeseed Safflower
Sesame Seed Soya Bean Sunflower Seed Walnut MANY OTHERS not listed
You can check the following link about our oil press :
/watch?v=qk_bF88mweM
Why Choose Us?
machines undergoes an extensive and strict testing and quality control procedure, ensuring each and every item purchased meet global quality standards.
Before Purchase
Need any information of the item before customers' purchase. On-hand professional technical staff are willing to solve any problems in 24 hours.And an instruction attached with machines' package before the shippment.
Factory Price
Most of machines are produced in our own factory ,thus we can offer you the best price and best technical service at the same time . is committed to providing high quality merchandise with good price.
Payment Method
These payments of T/T, Western Union, Paypal are accepeted. Any problem with payment during the course of payment, some instruction will be offered, only drop your questions by mail, Skype, MSN. Our staff will answer you within 24 hours.
Logistics
Cooperated with reliable internationally trusted logistic service provider such as DHL, EMS and UPS, ship to exceeding 100 countries around the world. A favorable choice of logistic company from our customer is accepted. The goods is frequently shipped out within 3 workdays, not including special important chinese festivals in china.
Tracking Number
We will inform customers of date of shippment, and tracking number will be confirmed, then write to inform our customers in 2-3 days after delivery goods.
Complainment
Any comments, suggestions are appreciated from our customers. Customers' comments will be along with our growing-up experience. will be very grateful to that.
